G50F1C-P Series
Manufacturer: ODU
Beta
⌘K
ODU MINI-SNAP RECEPT, STY 5, SZ
| Part | Current Rating (Amps) | Applications | Ingress Protection | Mounting Feature | Insert Material | Contact Material | Contact Finish - Mating | Mounting Type | Shell Size - Insert [custom] | Shell Finish | Material Flammability Rating | Color | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Orientation [custom] | Fastening Type | Voltage Rating | Primary Material | Shell Material | Number of Positions | Connector Type | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
7.5 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | Unshielded | 120 °C | -40 C | 1 | Push-Pull | 300 VDC | Metal | Brass | 4 | Receptacle Female Sockets | ||
7.5 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | 120 °C | -40 C | 1 | Push-Pull | Metal | Brass | Receptacle Female Sockets | |||||
4 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | 120 °C | -40 C | 1 | Push-Pull | Metal | Brass | 9 | Receptacle Female Sockets | ||||
4 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount Through Hole | 0 | Chrome over Nickel | UL94 V-0 | Silver | Unshielded | 120 °C | -40 C | 1 | Push-Pull | 300 VDC | Metal | Brass | 7 | Receptacle Female Sockets | Solder | |
6 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | Unshielded | 120 °C | -40 C | 1 | Push-Pull | 300 VDC | Metal | Brass | 4 | Receptacle Female Sockets | ||
7.5 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | Unshielded | 120 °C | -40 C | 1 | Push-Pull | 300 VDC | Metal | Brass | 4 | Receptacle Female Sockets | ||
4 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | 120 °C | -40 C | 1 | Push-Pull | Metal | Brass | 7 | Receptacle Female Sockets | ||||
7.5 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | Unshielded | 120 °C | -40 C | 1 | Push-Pull | 500 V | Metal | Brass | 2 | Receptacle Female Sockets | ||
6 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount | 0 | Chrome over Nickel | UL94 V-0 | Silver | Unshielded | 120 °C | -40 C | 1 | Push-Pull | 366 V | Metal | Brass | 5 | Receptacle Female Sockets | ||
6 A | Industrial Medical Military Testing Equipment & Measurement | IP50 - Dust Protected | Bulkhead - Front or Rear Side Nut | Polyetheretherketone (PEEK) | Brass | Gold | Panel Mount Through Hole | 0 | Chrome over Nickel | UL94 V-0 | Silver | Unshielded | 120 °C | -40 C | 1 | Push-Pull | 366 V | Metal | Brass | 5 | Receptacle Female Sockets | Solder |
