- Series
Manufacturer: WAGO Corporation
Catalog
RELAY GEN PURPOSE 4PDT 5A 220V
...
| Part | Load - Max Switching (Apparent Power) | Coil Voltage | Features | Release Time | Contact Rating (Current) | Switching Voltage AC (Max) | Contact Material | Relay Type | Operating Temperature (Max) | Operating Temperature (Min) | Termination Style | Mounting Type | Coil Type | Operate Time | Pin Count | Contact Form | Coil Current | Coil Resistance | Form A Count | Circuit | Approval Agency | Voltage - Input | Package / Case | Load Current | Output Type | Voltage - Load (Max) | Voltage - Load (Min) | Coil Voltage (Type) | Coil Voltage (Max) | Coil Voltage (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 WAGO Corporation | 1250 VA | 220 V | Lighted Indicator | 25 ms | 5 A | 250 VAC | Silver Cerium (AgCe) | General Purpose | 70 °C | -25 °C | Spring Terminal | DIN Rail | Non Latching | 25 ms | 4 | 4 C Form PDT | 4.1 mA | 53.66 kOhms | ||||||||||||
 WAGO Corporation | 4000 VA | 24 VDC | 3 ms | 16 A | 250 VAC | Gold (Au) Silver Nickel (AgNi) | General Purpose | 85 °C | -40 °C | PC Pin | Through Hole | Non Latching | 7 ms | 1 C Form SPDT | 17 mA | 1.41 kOhms | ||||||||||||||
 WAGO Corporation | 1500 VA | 24 VDC | Lighted Indicator | 4 ms | 6 A | 250 VAC | Silver Tin Oxide (AgSnO) | General Purpose | 70 °C | -40 °C | Plug In | Socketable | Non Latching | 8 ms | SPST-NO | 6.6 mA | 3.64 kOhms | 1 | ||||||||||||
 WAGO Corporation | 70 °C | -20 °C | Spring Terminal | DIN Rail | SPST-NO (1 Form A) | UL | 24 V 24 V | Module | 4 A | AC Zero Cross | 275 V | 12 V | ||||||||||||||||||
 WAGO Corporation | 1500 VA | 230 VDC | 25 ms | 6 A | 250 VAC | Gold (Au) Silver Nickel (AgNi) | General Purpose | 60 °C | -40 °C | Spring Terminal | DIN Rail | Non Latching | 15 ms | 1 C Form SPDT | 3.5 mA | 65.71 kOhms | EAC UL | AC DC | ||||||||||||
 WAGO Corporation | 1250 VA | 24 VDC | Lighted Indicator | 6 ms | 5 A | 250 VAC | Silver Nickel (AgNi) | General Purpose | 70 °C | -40 °C | Plug In | Socketable | Non Latching | 8 ms | 4 | 4 Form A PST-NO | 28.1 mA | 854.09 Ohms | ||||||||||||
 WAGO Corporation | 2000 VA | 230 VDC | Lighted Indicator | 8 ms | 8 A | 250 VAC | Silver Nickel (AgNi) | General Purpose | 70 °C | -40 °C | Spring Terminal | DIN Rail | Non Latching | 15 ms | 2 2 Form C C DPDT Form | 3.2 mA | 71.88 kOhms | |||||||||||||
 WAGO Corporation | 750 VA | Lighted Indicator | 6 ms | 3 A | 250 VAC | Silver Nickel (AgNi) | General Purpose | 50 °C | -40 °C | Plug In | Socketable | Non Latching | 8 ms | 4 | 2 A B Form PST-2NO/2NC | 6 mA | 38.33 kOhms | AC DC | 230 VAC/DC | 24 VAC | ||||||||||
 WAGO Corporation | 1000 VA | 24 VDC | Lighted Indicator | 20 ms | 4 A | 250 VAC | Gold (Au) Silver Nickel (AgNi) | General Purpose | 40 °C | -20 °C | Spring Terminal | DIN Rail | Non Latching | 20 ms | 4 | 4 Form A PST-NO | 12 mA | 2000 Ohms | EAC | AC DC | ||||||||||
 WAGO Corporation | 1500 VA | 24 VDC | 4 ms | 6 A | 250 VAC | Silver Nickel (AgNi) | General Purpose | 85 °C | -40 °C | PC Pin | Through Hole | Non Latching | 8 ms | 1 C Form SPDT | UL |
