860-003 Series
Manufacturer: NorComp Inc.
Beta
⌘K
SENSOR CONNECTOR, UNSHIELDED, VULCON SERIES, M12, FEMALE, 3 POSITIONS, PCB SOCKET
| Part | Voltage Rating | Ingress Protection | Shell Material | Color | Contact Finish - Mating | Fastening Type | Material Flammability Rating | Shell Size - Insert | Orientation | Contact Material | Mounting Feature | Termination | Shell Finish | Insert Material | Connector Type | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Primary Material | Shielding | Current Rating (Amps) | Applications | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 250 V | IP67 - Dust Tight Waterproof | Brass | Silver | Gold | Threaded | UL94 V-0 | M12-3 | A | Brass | Bulkhead - Front Side Nut | Solder | Nickel | Polybutylene Terephthalate (PBT) | Plug Female Sockets | 85 °C | -40 C | Panel Mount Through Hole | 0.25 µm | 10 µin | Metal | Shielded | 4 A | Industrial Medical | |
 NorComp Inc. | 250 V | IP67 - Dust Tight Waterproof | Brass | Silver | Gold | Threaded | UL94 V-0 | M12-3 | A | Brass | Bulkhead - Front Side Nut | Solder | Nickel | Polybutylene Terephthalate (PBT) | Receptacle Male Pins | 85 °C | -40 C | Panel Mount Through Hole | Metal | Shielded | 4 A | Industrial Medical | Flash |
