612F Series

Catalog

FAN AXIAL 60X15MM 12VDC WIRE

Part	Material - Blade	Material - Frame	Lifetime @ Temp.	Bearing Type	Approval Agency	Size / Dimension [z]	Size / Dimension [x]	Noise	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Fan Type	Power (Watts)	Weight	Weight	Voltage - Rated	RPM	Air Flow	Air Flow	Termination	Width [y]	Features	Voltage Range [Max]	Voltage Range [Min]	Weight [custom]	Weight [custom]
ebm-papst Inc. 612FH	Polyamide (PA) Nylon Fiberglass Reinforced	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	45000 Hrs	Sintec	CE CSA UL VDE	60 mm	60 mm	31 dB(A)	60 °C	60 °C	-4 °F	-20 ░C	Tubeaxial	1.4 W	0.066 lb	29.94 g	12 VDC	4500 RPM	19.4 CFM	0.543 m³/min	2 Wire Leads	15 mm
ebm-papst Inc. 612F/2H	Polyamide (PA) Nylon Fiberglass Reinforced	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	45000 Hrs	Sintec		60 mm	60 mm	37 dB	60 °C	60 °C	-4 °F	-20 ░C	Tubeaxial	1.5 W			12 VDC	4500 RPM	19.4 CFM	0.543 m³/min	3 Wire Leads	15 mm	Locked Rotor Protection Speed Sensor (Tach)
ebm-papst Inc. 612FL	Polyamide (PA) Nylon Fiberglass Reinforced	Fiberglass Reinforced Polybutylene Terephthalate (PBT)		Sintec	CE CSA UL VDE	60 mm	60 mm	16 dB					Tubeaxial	0.4 W			12 VDC	2650 RPM	11.2 CFM	0.314 m³/min	2 Wire Leads	15 mm		13.2 VDC	11.5 VDC	27.22 g	0.06 lb
ebm-papst Inc. 612F/2-638	Polyamide (PA) Nylon Fiberglass Reinforced	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	50000 Hrs	Sintec		60 mm	60 mm	35 dB		167 °F		-4 °F	Tubeaxial				12 VDC	3900 RPM	15.9 CFM	0.445 mł/min	3 Position Rectangular Connector	15 mm	Locked Rotor Protection Speed Sensor (Tach)	13.2 VDC	10.8 VDC
