GRS-2011 Series
Manufacturer: CW Industries
Beta
⌘K
SWITCH ROCKER SPST 13A 125V
| Part | Mechanical Life | Electrical Life | Termination Style | Mounting Type | Voltage Rating - AC | Circuit | Current Rating (Amps) | Actuator Type | Actuator Marking | Panel Cutout Dimensions [y] | Panel Cutout Dimensions [x] | Switch Function | Operating Temperature [Min] | Operating Temperature [Max] | Color - Actuator/Cap | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 13 A | Concave (Curved) | ON OFF | 13.97 mm | 28.58 mm | On-Off | -20 ░C | 105 ░C | Black | |
 CW Industries | 100000 Cycles | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 16 A | Concave (Curved) | No Marking | 13.97 mm | 28.58 mm | On-Off | -20 ░C | 105 ░C | Black | |
 CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 16 A | Concave (Curved) | No Marking | 13.97 mm | 28.58 mm | On-Off | -20 ░C | 105 ░C | Black | Terminal Barriers |
 CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 8 A | Concave (Curved) | O - | 13.97 mm | 28.58 mm | On-Off | -20 ░C | 105 ░C | White | |
 CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST-NO | 13 A | Concave (Curved) | No Marking | 12.19 mm | 27.23 mm | Off-Mom | -20 ░C | 105 ░C | Black | Terminal Barriers |
CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 16 A | Concave (Curved) | No Marking | 12.19 mm | 27.23 mm | On-Off | -20 ░C | 105 ░C | Black | Terminal Barriers |
 CW Industries | 100000 Cycles | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 16 A | Concave (Curved) | O - | 13.97 mm | 28.58 mm | On-Off | -20 ░C | 105 ░C | Black | |
 CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST-NC | 13 A | Concave (Curved) | No Marking | 12.19 mm | 27.23 mm | On-Mom | -20 ░C | 105 ░C | Black | Polarized |
 CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 16 A | Concave (Curved) | No Marking | 12.19 mm | 27.23 mm | On-Off | -20 ░C | 105 ░C | Black | Terminal Barriers |
 CW Industries | 25000 Steps | 25000 Steps | Quick Connect - 0.250" (6.3mm) | Panel Mount Snap-In | 125 V | SPST | 13 A | Concave (Curved) | HI LO | 13.97 mm | 28.58 mm | On-Off | -20 ░C | 105 ░C | Black |
