LYT64F Series

Catalog

LED YELLOW CLEAR 2PLCC SMD

Part	Millicandela Rating	Wavelength - Peak	Lens Style	Supplier Device Package	Lens Size [diameter]	Size / Dimension [y]	Size / Dimension [x]	Color	Current - Test	Mounting Type	Lens Transparency	Voltage - Forward (Vf) (Typ)	Wavelength - Dominant	Lens Color	Package / Case	Viewing Angle	Height (Max) [Max] [z]	Configuration
ams-OSRAM USA INC. LY T64F-BBDA-35-1-20-R33-Z	4950 mcd	597 nm	Round with Domed Top	2-PLCC	2.6 mm Dia	2.8 mm	3.2 mm	Yellow	20 mA	Surface Mount	Clear	2.2 V	590 nm	Colorless	2-PLCC	30 °	3.8 mm	Standard
ams-OSRAM USA INC. LY T64F-BBDA-35-1-Z	4950 mcd	597 nm	Round with Domed Top	2-PLCC	2.6 mm Dia	2.8 mm	3.2 mm	Yellow	20 mA	Surface Mount	Clear	2.2 V	590 nm	Colorless	2-PLCC	30 °	3.8 mm	Standard
