eUSB2 to USB 2.0 Dual repeater
Key Features
• Compliance to USB 2.0 and eUSB2 (rev 1.1)Support for low-speed (LS), full-speed (FS), high-speed (HS)Dual repeater with 2:2 crossbar muxHost and device mode (DRD) supportFour eUSB2 compensation settings to meet different system requirementseUSB2 LS/FS signaling meets 1.2V option of the eUSB2 interfaceCompliance to USB 2.0 and eUSB2 (rev 1.1)Support for low-speed (LS), full-speed (FS), high-speed (HS)Dual repeater with 2:2 crossbar muxHost and device mode (DRD) supportFour eUSB2 compensation settings to meet different system requirementseUSB2 LS/FS signaling meets 1.2V option of the eUSB2 interface
Description
AI
TUSB2E22 enables implementation of USB 2.0 compliance port on newer processors using lower voltage processes.
TUSB2E22 is a USB-compliant eUSB2-USB 2.0 repeater supporting both device and host modes.
TUSB2E22 supports USB low-speed (LS) and full-speed (FS) signals and high-speed (HS) signals.
TUSB2E22 is designed to interface with eUSB2 eDSPr or eUSPr operating at 1.2V single-ended signaling.
TUSB2E22 has four levels of compensation settings through the EQ0 and EQ1 pins. These settings can be used to optimize compensation for different eUSB2 channel loss profiles.
TUSB2E22 enables implementation of USB 2.0 compliance port on newer processors using lower voltage processes.
TUSB2E22 is a USB-compliant eUSB2-USB 2.0 repeater supporting both device and host modes.
TUSB2E22 supports USB low-speed (LS) and full-speed (FS) signals and high-speed (HS) signals.
TUSB2E22 is designed to interface with eUSB2 eDSPr or eUSPr operating at 1.2V single-ended signaling.
TUSB2E22 has four levels of compensation settings through the EQ0 and EQ1 pins. These settings can be used to optimize compensation for different eUSB2 channel loss profiles.
