396-046 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 46POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Color | Number of Rows [custom] | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Mounting Type | Read Out | Contact Finish | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Termination | Card Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Features | Number of Positions/Bay/Row | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | 2 | 46 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Board Edge Straddle Mount | Dual | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Solder | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Card Extender | 23 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | 2 | 46 | 0.128 " | 3.25 mm | Right Angle Through Hole | Dual | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Solder Wire Wrap | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 23 | ||||
 EDAC Inc. | Polyester Thermoplastic | Black | 46 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Through Hole | Single | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Solder | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 46 | 1 | 1 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | 2 | 46 | M3 Threaded Insert Top Mount Opening | Through Hole | Dual | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 23 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | 2 | 46 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Through Hole | Dual | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 23 | |||
 EDAC Inc. | Polyester Thermoplastic | Black | 46 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Through Hole | Single | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Solder | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 46 | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | Black | 46 | Through Hole | Single | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Wire Wrap | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 46 | 1 | 1 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Black | 46 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Through Hole | Single | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Wire Wrap | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 46 | 1 | 1 | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Black | 2 | 46 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Through Hole | Dual | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 23 | |||
 EDAC Inc. | Polyester Thermoplastic | Black | 46 | 4-40 Threaded Insert Top Mount Opening | Through Hole | Single | Gold | Cantilever | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Copper Alloy | Wire Wrap | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 46 | 1 | 1 |
