RBE05 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN EDGE DUAL FMALE 10POS 0.039

Part	Material - Insulation	Card Type	Contact Type	Number of Positions	Read Out	Pitch	Pitch	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Card Thickness	Card Thickness	Contact Finish Thickness	Contact Finish Thickness	Contact Material	Number of Positions/Bay/Row	Gender	Contact Finish	Mounting Type	Color	Number of Rows [custom]	Features	Flange Feature	Flange Feature [diameter]	Flange Feature [diameter]
Sullins Connector Solutions RBE05DHHN	Polyphenylene Sulfide (PPS)	Non Specified - Dual Edge	Hairpin Bellows	10	Dual	1 mm	0.039 in	Solder Staggered	-65 ░C	125 °C	1.57 mm	0.062 in	0.25 Ám	10 Áin	Phosphor Bronze	5	Female	Gold	Through Hole	Black	2
Sullins Connector Solutions RBE05DHFR	Polyphenylene Sulfide (PPS)	Non Specified - Dual Edge	Hairpin Bellows	10	Dual	1 mm	0.039 in	Solder	-65 ░C	125 °C	1.57 mm	0.062 in	0.25 Ám	10 Áin	Phosphor Bronze	5	Female	Gold	Surface Mount	Black	2	Board Lock
Sullins Connector Solutions RBE05DHHD	Polyphenylene Sulfide (PPS)	Non Specified - Dual Edge	Hairpin Bellows	10	Dual	1 mm	0.039 in	Solder Staggered	-65 ░C	125 °C	1.57 mm	0.062 in	0.25 Ám	10 Áin	Phosphor Bronze	5	Female	Gold	Through Hole	Black	2		Flush Mount Top Opening Unthreaded	3.18 mm	0.125 "
Sullins Connector Solutions RBE05DHRD	Polyphenylene Sulfide (PPS)	Non Specified - Dual Edge	Hairpin Bellows	10	Dual	1 mm	0.039 in	Solder	-65 ░C	125 °C	1.57 mm	0.062 in	0.25 Ám	10 Áin	Phosphor Bronze	5	Female	Gold	Board Edge Straddle Mount	Black	2	Card Extender	Flush Mount Top Opening Unthreaded	3.18 mm	0.125 "
Sullins Connector Solutions RBE05DHRT	Polyphenylene Sulfide (PPS)	Non Specified - Dual Edge	Hairpin Bellows	10	Dual	1 mm	0.039 in	Solder	-65 ░C	125 °C	1.57 mm	0.062 in	0.25 Ám	10 Áin	Phosphor Bronze	5	Female	Gold	Board Edge Straddle Mount	Black	2	Card Extender	4-40 Flush Mount Threaded Insert Top Opening
Sullins Connector Solutions RBE05DHAS	Polyphenylene Sulfide (PPS)	Non Specified - Dual Edge	Hairpin Bellows	10	Dual	1 mm	0.039 in	Solder Staggered	-65 ░C	125 °C	1.57 mm	0.062 in	0.25 Ám	10 Áin	Phosphor Bronze	5	Female	Gold	Right Angle Through Hole	Black	2		Side Mount Opening Unthreaded	3.18 mm	0.125 "
Sullins Connector Solutions RBE05DHFT	Polyphenylene Sulfide (PPS)	Non Specified - Dual Edge	Hairpin Bellows	10	Dual	1 mm	0.039 in	Solder	-65 ░C	125 °C	1.57 mm	0.062 in	0.25 Ám	10 Áin	Phosphor Bronze	5	Female	Gold	Surface Mount	Black	2		4-40 Flush Mount Threaded Insert Top Opening
