25010/15 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 15COND 22AWG RED 1000'
| Part | Number of Conductors | Jacket Color | Voltage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Conductor Material | Jacket (Insulation) Material | Features | Ratings | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Strand [custom] | Conductor Strand [custom] | Wire Gauge | Cable Type | Conductor Insulation | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 15 | Red | 300 VDC | 0.299 " | 7.6 mm | -30 ░C | 90 °C | Copper Tinned | Polyurethane (PU) | Biological Compatibility Rip Cord | ISO 10993 UL Style 20668 | 0.813 mm | 0.032 in | 30 AWG | 7 | 22 AWG | Multi-Conductor | Poly-Vinyl Chloride (PVC) | ||
 ALPHA WIRE | 15 | Black | 300 VDC | 0.299 " | 7.6 mm | -30 ░C | 90 °C | Copper Tinned | Polyurethane (PU) | Biological Compatibility Rip Cord | ISO 10993 UL Style 20668 | 0.813 mm | 0.032 in | 30 AWG | 7 | 22 AWG | Multi-Conductor | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft |
