857-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 18POS 0.156
| Part | Material - Insulation | Termination Rows | Pitch | Pitch | Mounting Type | Read Out | Number of Positions | Number of Rows [custom] | Contact Type | Card Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Number of Positions/Bay/Row | Termination | Color | Number of Rows | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Dual | 18 | 2 | Semi Bellows | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 125 °C | -40 C | Tin | 9 | Solder | Black | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Through Hole | Single | 9 | Semi Bellows | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | 125 °C | -40 C | Tin | 9 | Wire Wrap | Black | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Dual | 18 | 2 | Semi Bellows | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | Gold | 9 | Solder | Black | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Dual | 18 | 2 | Semi Bellows | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Copper Alloy | 125 °C | -40 C | Tin | 9 | Solder | Black | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Single | 9 | Semi Bellows | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 125 °C | -40 C | Tin | 9 | Solder | Black | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Dual | 18 | 2 | Semi Bellows | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 125 °C | -40 C | Tin | 9 | Solder | Black | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Single | 9 | Semi Bellows | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | 125 °C | -40 C | Tin | 9 | Solder | Black | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Single | 9 | Semi Bellows | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | 125 °C | -40 C | Tin | 9 | Solder | Black | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Right Angle Through Hole | Single | 9 | Semi Bellows | Non Specified - Single Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 125 °C | -40 C | Tin | 9 | Solder | Black | 1 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 3.96 mm | 0.156 in | Through Hole | Dual | 18 | 2 | Semi Bellows | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 125 °C | -40 C | Gold | 9 | Solder Eyelet(s) | Black | 0.25 Ám | 10 Áin |
