CR-1-3056 Series

Catalog

PMI DIA .319" (8.10MM) RED 120VA

Part	Voltage	Current	Lens Style	Panel Cutout Shape	Lens Color	Millicandela Rating	Ratings	Lamp Color	Panel Cutout Dimensions	Panel Cutout Dimensions	Wavelength - Peak	Type	Viewing Angle	Termination Style
Visual Communications Company - VCC CR-1-3056-9920-I	1.9 V 120 V	20 mA	Round with Domed Top	Round	Red	400 mcd	AC	Red	0.32 "	8.1 mm	660 nm	LED	30 °	Wire Leads - 6.000" (152.40mm)
Visual Communications Company - VCC CR-1-3056-0000-I	1.9 V	20 mA	Round with Domed Top	Round	Red	400 mcd		Red	0.32 "	8.1 mm	660 nm	LED	30 °	Wire Leads - 6.000" (152.40mm)
Visual Communications Company - VCC CR-1-3056-9908-I	1.9 V 12 V	20 mA	Round with Domed Top	Round	Red	400 mcd	DC	Red	0.32 "	8.1 mm	660 nm	LED	30 °	Wire Leads - 6.000" (152.40mm)
Visual Communications Company - VCC CR-1-3056-9910-I	1.9 V 24 V	20 mA	Round with Domed Top	Round	Red	400 mcd	DC	Red	0.32 "	8.1 mm	660 nm	LED	30 °	Wire Leads - 6.000" (152.40mm)
Visual Communications Company - VCC CR-1-3056-9914-I	1.9 V 60 V	20 mA	Round with Domed Top	Round	Red	400 mcd	DC	Red	0.32 "	8.1 mm	660 nm	LED	30 °	Wire Leads - 6.000" (152.40mm)
Visual Communications Company - VCC CR-1-3056-9912-I	1.9 V 48 V	20 mA	Round with Domed Top	Round	Red	400 mcd	DC	Red	0.32 "	8.1 mm	660 nm	LED	30 °	Wire Leads - 6.000" (152.40mm)
Visual Communications Company - VCC CR-1-3056-9907-I	1.9 V 5 V	20 mA	Round with Domed Top	Round	Red	400 mcd	DC	Red	0.32 "	8.1 mm	660 nm	LED	30 °	Wire Leads - 6.000" (152.40mm)
