895-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 58POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Finish | Mounting Type | Gender | Number of Positions | Color | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Positions/Bay/Row | Card Type | Pitch | Pitch | Read Out | Contact Type | Termination | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] | Features | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Right Angle Through Hole | Female | 58 | Black | 125 °C | -40 C | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 58 | Non Specified - Single Edge | 0.1 " | 2.54 mm | Single | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Board Edge Straddle Mount | Female | 58 | Black | 125 °C | -40 C | 3.96 mm | 0.156 " | 29 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 2 | Card Extender | 2 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | 1 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 58 | Non Specified - Single Edge | 0.1 " | 2.54 mm | Single | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 58 | Non Specified - Single Edge | 0.1 " | 2.54 mm | Single | Cantilever | Wire Wrap | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | 29 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | 29 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | 3.25 mm | 0.128 " | 29 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 2 | 2 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | 29 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 2 | 2 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 29 | Non Specified - Dual Edge | 0.1 " | 2.54 mm | Dual | Cantilever | Wire Wrap | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 2 | 2 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | Through Hole | Female | 58 | Black | 125 °C | -40 C | 1 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 58 | Non Specified - Single Edge | 0.1 " | 2.54 mm | Single | Cantilever | Solder | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin |
