1971817 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
5P,RAST 2.5 TAB HEADER,EX- LOCKI
| Part | Contact Finish - Post | Contact Shape | Termination | Insulation Color | Connector Type | Contact Material | Insulation Material | Features | Material Flammability Rating | Applications | Style | Number of Rows | Fastening Type | Insulation Height | Insulation Height | Pitch - Mating | Pitch - Mating | Mounting Type | Number of Positions Loaded | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Shrouding | Contact Length - Post | Contact Length - Post | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | ||||||||||||||||||||||||||
 TE Connectivity Raychem Cable Protection | Tin | Rectangular | Solder | Natural | Header | Copper Alloy | Nylon Polyamide (PA) | Board Guide Glow Wire Compliant | UL94 V-0 | General Purpose | Board to Cable/Wire | 1 | Locking Ramp | 0.61 in | 15.49 mm | 2.5 mm | 0.098 in | Through Hole | All | Tab | -40 °C | 120 °C | Shrouded - 4 Wall | 0.114 in | 2.9 mm | |
 TE Connectivity Raychem Cable Protection | Tin | Rectangular | Solder | Natural | Header | Copper Alloy | Nylon Polyamide (PA) | Board Guide Glow Wire Compliant | UL94 V-0 | General Purpose | Board to Cable/Wire | 1 | Locking Ramp | 0.61 in | 15.49 mm | 2.5 mm | 0.098 in | Through Hole | All | Tab | -40 °C | 120 °C | Shrouded - 4 Wall | 0.114 in | 2.9 mm | 4 |
 TE Connectivity Raychem Cable Protection | Tin | Rectangular | Solder | Natural | Header | Copper Alloy | Nylon Polyamide (PA) | Board Guide Glow Wire Compliant | UL94 V-0 | General Purpose | Board to Cable/Wire | 1 | Locking Ramp | 0.61 in | 15.49 mm | 2.5 mm | 0.098 in | Through Hole | All | Tab | -40 °C | 120 °C | Shrouded - 4 Wall | 0.114 in | 2.9 mm | 4 |
 TE Connectivity Raychem Cable Protection | Tin | Rectangular | Solder | Natural | Header | Copper Alloy | Nylon Polyamide (PA) | Board Guide Glow Wire Compliant | UL94 V-0 | General Purpose | Board to Cable/Wire | 1 | Locking Ramp | 0.61 in | 15.49 mm | 2.5 mm | 0.098 in | Through Hole | All | Tab | -40 °C | 120 °C | Shrouded - 4 Wall | 0.114 in | 2.9 mm | 8 |
TE Connectivity Raychem Cable Protection | ||||||||||||||||||||||||||
 TE Connectivity Raychem Cable Protection | Tin | Rectangular | Solder | Natural | Header | Copper Alloy | Nylon Polyamide (PA) | Board Guide Glow Wire Compliant | UL94 V-0 | General Purpose | Board to Cable/Wire | 1 | Locking Ramp | 0.61 in | 15.49 mm | 2.5 mm | 0.098 in | Through Hole | All | Tab | -40 °C | 120 °C | Shrouded - 4 Wall | 0.114 in | 2.9 mm | 9 |
