PRPC004 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN HEADER VERT 8POS 2.54MM
| Part | Contact Finish Thickness - Post | Connector Type | Termination | Contact Finish Thickness - Mating | Contact Finish - Post | Insulation Height | Insulation Height | Insulation Color | Contact Type | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Number of Positions | Insulation Material | Overall Contact Length [x] | Overall Contact Length [x] | Current Rating (Amps) | Style | Contact Length - Mating | Contact Length - Mating | Number of Positions Loaded | Pitch - Mating | Pitch - Mating | Shrouding | Contact Length - Post | Contact Length - Post | Mounting Type | Contact Shape | Material Flammability Rating | Contact Finish - Mating | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Fastening Type | Number of Rows | Overall Contact Length | Overall Contact Length | Overall Contact Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 0.1 in | 2.54 mm | 8 | Polybutylene Terephthalate (PBT) | 13.63 mm | 0.537 in | 3 A | Board to Board Cable | 8.08 mm | 0.318 in | All | 0.1 " | 2.54 mm | Unshrouded | 3.05 mm | 0.12 in | Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | 2 | Push-Pull | ||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 4 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 8.08 mm | 0.318 in | All | 0.1 " | 2.54 mm | Unshrouded | 3.05 mm | 0.12 in | Right Angle Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | Push-Pull | 1 | ||||||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 0.1 in | 2.54 mm | 8 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 8.08 mm | 0.318 in | All | 0.1 " | 2.54 mm | Unshrouded | 5.58 mm | 0.22 in | Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | 2 | Push-Pull | 0.637 in | 16.17 mm | ||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 4 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 5.84 mm | 0.23 in | All | 0.1 " | 2.54 mm | Unshrouded | 8.13 mm | 0.32 in | Right Angle Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | Push-Pull | 1 | ||||||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 0.1 in | 2.54 mm | 8 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 5.84 mm | 0.23 in | All | 0.1 " | 2.54 mm | Unshrouded | 3.05 mm | 0.12 in | Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | 2 | Push-Pull | 11.39 mm | 0.448 in | ||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.197 " | 5 mm | Black | Male Pin | 0.1 in | 2.54 mm | 8 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 5.84 mm | 0.23 in | All | 0.1 " | 2.54 mm | Unshrouded | 5.58 mm | 0.22 in | Right Angle Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | 2 | Push-Pull | ||||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 4 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 5.84 mm | 0.23 in | All | 0.1 " | 2.54 mm | Unshrouded | 3.05 mm | 0.12 in | Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | Push-Pull | 1 | 11.39 mm | 0.448 in | ||||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 4 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 5.84 mm | 0.23 in | All | 0.1 " | 2.54 mm | Unshrouded | 5.58 mm | 0.22 in | Right Angle Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | Push-Pull | 1 | ||||||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 4 | Polybutylene Terephthalate (PBT) | 16.47 mm | 0.648 in | 3 A | Board to Board Cable | 5.84 mm | 0.23 in | All | 0.1 " | 2.54 mm | Unshrouded | 8.13 mm | 0.32 in | Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | Push-Pull | 1 | ||||||
 Sullins Connector Solutions | Flash | Header Breakaway | Solder | Flash | Gold | 0.098 " | 2.5 mm | Black | Male Pin | 0.1 in | 2.54 mm | 8 | Polybutylene Terephthalate (PBT) | 3 A | Board to Board Cable | 5.84 mm | 0.23 in | All | 0.1 " | 2.54 mm | Unshrouded | 5.84 mm | 0.23 " | Through Hole | Square | UL94 V-0 | Gold | Brass | -40 C | 105 ░C | 2 | Push-Pull | 14.18 mm | 0.558 in |
