68465 Series

Catalog

CONN HEADER VERT 7POS 2.54MM

Part	Number of Positions Loaded	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Mating	Contact Type	Pitch - Mating	Pitch - Mating	Number of Positions	Mounting Type	Insulation Height	Insulation Height	Fastening Type	Overall Contact Length	Overall Contact Length	Insulation Color	Contact Shape	Material Flammability Rating	Connector Type	Shrouding	Contact Length - Post [x]	Contact Length - Post [x]	Termination	Contact Length - Mating [x]	Contact Length - Mating	Contact Material	Contact Finish - Post
Amphenol ICC (FCI) 68465-107HLF	All	1	30 Áin	0.76 Ám	Gold or Gold GXT™	Male Pin	0.1 in	2.54 mm	7	Through Hole	0.1 in	2.54 mm	Push-Pull	0.925 in	23.5 mm	Black	Square	UL94 V-0	Header	Unshrouded	15.11 mm	0.595 in	Solder	0.23 in	5.84 mm	Phosphor Bronze
Amphenol ICC (FCI) 68465-636	All	1	30 Áin	0.76 Ám	Gold or Gold GXT™	Male Pin	0.1 in	2.54 mm	36	Through Hole	0.1 in	2.54 mm	Push-Pull	0.925 in	23.5 mm	Black	Square	UL94 V-0	Header	Unshrouded	15.11 mm	0.595 in	Solder	0.23 in	5.84 mm	Phosphor Bronze
Amphenol ICC (FCI) 68465-436	All	1	100 çin	2.54 çm		Male Pin	0.1 in	2.54 mm	36	Through Hole	0.1 in	2.54 mm	Push-Pull	0.925 in	23.5 mm	Black	Square	UL94 V-0	Header	Unshrouded	15.11 mm	0.595 in	Solder	0.23 in	5.84 mm	Phosphor Bronze
Amphenol ICC (FCI) 68465-436HLF	All	1	100 çin	2.54 çm		Male Pin	0.1 in	2.54 mm	36	Through Hole	0.1 in	2.54 mm	Push-Pull	0.925 in	23.5 mm	Black	Square	UL94 V-0	Header	Unshrouded	15.11 mm	0.595 in	Solder	0.23 in	5.84 mm	Phosphor Bronze	Tin
Amphenol ICC (FCI) 68465-336HLF	All	1	50 µin	1.27 µm	Gold or Gold GXT™	Male Pin	0.1 in	2.54 mm	36	Through Hole	0.1 in	2.54 mm	Push-Pull	0.925 in	23.5 mm	Black	Square	UL94 V-0	Header	Unshrouded	15.11 mm	0.595 in	Solder	0.23 in	5.84 mm	Phosphor Bronze
Amphenol ICC (FCI) 68465-236	All	1	15 µin	0.38 µm	Gold or Gold GXT™	Male Pin	0.1 in	2.54 mm	36	Through Hole	0.1 in	2.54 mm	Push-Pull	0.925 in	23.5 mm	Black	Square	UL94 V-0	Header	Unshrouded	15.11 mm	0.595 in	Solder	0.23 in	5.84 mm	Phosphor Bronze
