CONN HEADER SMD 64POS 2.54MM

...

Part	Contact Shape	Connector Type	Pitch - Mating	Pitch - Mating	Shrouding	Contact Material	Insulation Material	Number of Positions	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Termination	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Type	Number of Positions Loaded	Fastening Type	Contact Finish - Mating	Contact Finish - Post	Number of Rows [custom]	Contact Length - Mating	Contact Length - Mating	Mounting Type	Overall Contact Length	Overall Contact Length	Contact Length - Post	Contact Length - Post	Insulation Height	Insulation Height	Overall Contact Length [x]	Overall Contact Length [x]	Contact Length - Mating [x]	Contact Length - Post [x]	Contact Length - Post [x]	Insulation Height [z]	Insulation Height [z]
Mill-Max Manufacturing Corp. 802-10-064-30-001000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	64	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	4.95 mm	0.195 in	Surface Mount
Mill-Max Manufacturing Corp. 802-10-052-10-004000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	52	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	3.18 mm	0.125 in	Through Hole	0.33 in	8.38 mm	0.125 in	3.18 mm	1.8 mm	0.071 in
Mill-Max Manufacturing Corp. 802-10-060-62-001000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	60	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Press-Fit Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	4.85 mm	0.191 in	Through Hole			0.143 in	3.63 mm			11.28 mm	0.444 in
Mill-Max Manufacturing Corp. 802-10-058-10-004000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	58	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	3.18 mm	0.125 in	Through Hole	0.33 in	8.38 mm	0.125 in	3.18 mm	1.8 mm	0.071 in
Mill-Max Manufacturing Corp. 802-10-036-10-007000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	36	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Press-Fit Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	4.2 mm		Through Hole	0.467 in	11.85 mm							0.165 in	4.24 mm	0.167 in
Mill-Max Manufacturing Corp. 802-10-094-10-004000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	94	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	3.18 mm	0.125 in	Through Hole	0.33 in	8.38 mm	0.125 in	3.18 mm	1.8 mm	0.071 in
Mill-Max Manufacturing Corp. 802-10-070-30-001000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	70	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	4.95 mm	0.195 in	Surface Mount
Mill-Max Manufacturing Corp. 802-10-056-20-001000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	56	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	4.95 mm	0.195 in	Right Angle Through Hole										3.2 mm	0.126 "	0.2 in	5.08 mm
Mill-Max Manufacturing Corp. 802-10-064-61-051000	Circular	Header	0.1 "	2.54 mm	Shrouded - 2 Wall	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	64	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Press-Fit Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	3.86 mm	0.152 in	Through Hole	0.386 in	9.8 mm	0.115 in	2.92 mm	6.88 mm	0.271 in
Mill-Max Manufacturing Corp. 802-10-030-30-001000	Circular	Header	0.1 "	2.54 mm	Unshrouded	Brass Alloy	Polycyclohexylenedimethylene Terephthalate (PCT)	30	Black	0.25 µm	10 µin	10 Áin	0.25 çm	Solder	0.1 in	2.54 mm	Male Pin	All	Push-Pull	Gold	Gold	2	4.95 mm	0.195 in	Surface Mount
