MCZ33999 Series

Catalog

IC PWR SWITCH N-CH 1:16 54SOIC

Part	Interface	Fault Protection	Features	Package / Case	Package / Case	Package / Case	Ratio - Input:Output	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Load [Min]	Voltage - Load [Max]	Output Configuration	Current - Output (Max) [Max]	Output Type	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Mounting Type	Number of Outputs	Supplier Device Package	Switch Type
Freescale Semiconductor - NXP MCZ33999EK	SPI	Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage	PWM Input	0.295 in	7.5 mm	54-SSOP	1:16	150 °C	-40 °C	5 V	27 V	Low Side	900 mA	N-Channel	3.1 V	5.5 V	Surface Mount	16	54-SOIC-EP	General Purpose
Freescale Semiconductor - NXP MCZ33999EKR2	SPI	Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage	PWM Input	0.295 in	7.5 mm	54-SSOP	1:16	150 °C	-40 °C	5 V	27 V	Low Side	900 mA	N-Channel	3.1 V	5.5 V	Surface Mount	16	54-SOIC-EP	General Purpose
