PYBJ15 Series

Manufacturer: CUI Inc.

Catalog

DC DC CONVERTER 5V 15W

Part	Standard Number	Operating Temperature [Min]	Operating Temperature [Max]	Number of Outputs	Voltage - Output 1	Features	Applications	Power (Watts)	Mounting Type	Voltage - Isolation	Package / Case	Efficiency	Voltage - Input (Max) [Max]	Approval Agency	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Current - Output (Max) [Max]	Voltage - Input (Min) [Min]	Type	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]
CUI Inc. PYBJ15-Q48-S5-M	55024 55032	-40 °C	85 °C	1	5 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Surface Mount	1.5 kV	15-SMD Module	88 %	75 V	EN	29.5 mm	39.1 mm	1.54 in	0.27 "	6.8 mm	1.16 in	3 A	18 V	Isolated Module
CUI Inc. PYBJ15-Q24-S3-OD	55024 55032	-40 °C	85 °C	1	3.3 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Through Hole	1.5 kV	14-DIP Module	88 %	36 V	EN		38.7 mm	1.52 in	0.24 in		1.07 in	4.5 A	9 V	Isolated Module	27.2 mm	6.2 mm
CUI Inc. PYBJ15-Q24-S15-D	55024 55032	-40 °C	85 °C	1	15 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Through Hole	1.5 kV	14-DIP Module	89 %	36 V	EN		39.1 mm	1.54 in	0.25 "		1.16 in	1 A	9 V	Isolated Module	29.5 mm	6.4 mm
CUI Inc. PYBJ15-Q24-S5-M	55024 55032	-40 °C	85 °C	1	5 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Surface Mount	1.5 kV	15-SMD Module	88 %	36 V	EN	29.5 mm	39.1 mm	1.54 in	0.27 "	6.8 mm	1.16 in	3 A	9 V	Isolated Module
CUI Inc. PYBJ15-Q48-S5-OD	55024 55032	-40 °C	85 °C	1	5 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Through Hole	1.5 kV	14-DIP Module	88 %	75 V	EN		38.7 mm	1.52 in	0.24 in		1.07 in	3 A	18 V	Isolated Module	27.2 mm	6.2 mm
CUI Inc. PYBJ15-Q24-S12-M		-40 °C	85 °C	1	12 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Surface Mount	1.5 kV	15-SMD Module	89 %	36 V	CE		39.1 mm	1.54 in	0.25 "		1.16 in	1.25 A	9 V	Isolated Module	29.5 mm	6.4 mm
CUI Inc. PYBJ15-Q24-S12-OD	55024 55032	-40 °C	85 °C	1	12 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Through Hole	1.5 kV	14-DIP Module	89 %	36 V	EN		38.7 mm					1.25 A	9 V	Isolated Module	27.2 mm	5.8 mm	1.07 "	0.23 in	1.52 "
CUI Inc. PYBJ15-Q24-S12-D	55024 55032	-40 °C	85 °C	1	12 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Through Hole	1.5 kV	14-DIP Module	89 %	36 V	EN		39.1 mm	1.54 in	0.25 "		1.16 in	1.25 A	9 V	Isolated Module	29.5 mm	6.4 mm
CUI Inc. PYBJ15-Q24-S3-D	55024 55032	-40 °C	85 °C	1	3.3 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Through Hole	1.5 kV	14-DIP Module	88 %	36 V	EN	29.5 mm	39.1 mm	1.54 in	0.27 "	6.8 mm	1.16 in	4.5 A	9 V	Isolated Module
CUI Inc. PYBJ15-Q48-S5-D	55024 55032	-40 °C	85 °C	1	5 V	OCP OVP Remote On/Off SCP	ITE (Commercial)	15 W	Through Hole	1.5 kV	14-DIP Module	88 %	75 V	EN	29.5 mm	39.1 mm	1.54 in	0.27 "	6.8 mm	1.16 in	3 A	18 V	Isolated Module
