EB167A Series
Manufacturer: Adam Tech
Beta
⌘K
EURO BLOCK, 2 POSITION
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Housing Material | Contact Material - Plating | Wire Gauge [Max] | Wire Gauge [Min] | Number of Levels | Wire Termination | Pitch | Pitch | Voltage | Positions Per Level | Color | Mating Orientation | Mounting Type | Current |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy - Tin Plated | 24 AWG | 8 AWG | 1 | Leg Spring Push-In Spring | 0.295 in | 7.5 mm | 600 V | 2 | Green | Vertical with Board | Through Hole | 40 A |
 Adam Tech | -40 C | 105 ░C | Copper Alloy - Tin Plated | 18 AWG | 4 AWG | 1 | Screwless - Spring Cage Tension Clamp | 0.394 in | 10 mm | 600 V | 5 | Green | Horizontal with Board | Through Hole | 66 A | |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy | 24 AWG | 8 AWG | 1 | Leg Spring Push-In Spring | 0.295 in | 7.5 mm | 600 V | 2 | Green | Horizontal with Board | Through Hole | 40 A |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy | 24 AWG | 8 AWG | 1 | Leg Spring Push-In Spring | 0.295 in | 7.5 mm | 600 V | 4 | Green | Horizontal with Board | Through Hole | 40 A |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy | 24 AWG | 8 AWG | 1 | Leg Spring Push-In Spring | 0.295 in | 7.5 mm | 600 V | 6 | Green | Horizontal with Board | Through Hole | 40 A |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy - Tin Plated | 24 AWG | 8 AWG | 1 | Leg Spring Push-In Spring | 0.295 in | 7.5 mm | 600 V | 5 | Green | Vertical with Board | Through Hole | 40 A |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy - Tin Plated | 18 AWG | 4 AWG | 1 | Leg Spring Push-In Spring | 0.394 in | 10 mm | 600 V | 6 | Green | Horizontal with Board | Through Hole | 66 A |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy - Tin Plated | 24 AWG | 8 AWG | 1 | Leg Spring Push-In Spring | 0.295 in | 7.5 mm | 600 V | 6 | Green | Vertical with Board | Through Hole | 40 A |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy - Tin Plated | 18 AWG | 4 AWG | 1 | Leg Spring Push-In Spring | 0.394 in | 10 mm | 600 V | 3 | Green | Horizontal with Board | Through Hole | 66 A |
 Adam Tech | -40 C | 105 ░C | Polyamide (PA) Nylon | Copper Alloy - Tin Plated | 18 AWG | 4 AWG | 1 | Leg Spring Push-In Spring | 0.394 in | 10 mm | 600 V | 5 | Green | Horizontal with Board | Through Hole | 66 A |
