TLV560 Series

Catalog

IC DAC 10BIT V-OUT DIESALE

Part	Data Interface	Number of D/A Converters	Architecture	Supplier Device Package	Settling Time	Mounting Type	Output Type	Package / Case	Number of Bits [custom]	Voltage - Supply, Analog	Voltage - Supply, Analog [Max]	Voltage - Supply, Analog [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Reference Type	INL/DNL (LSB)	Voltage - Supply, Digital [Min]	Voltage - Supply, Digital	Voltage - Supply, Digital [Max]	INL/DNL (LSB)	Package / Case [x]	Package / Case [y]	DAC Type	Supplied Contents	Number of DAC's	Utilized IC / Part	Package / Case [custom]	Package / Case
Texas Instruments TLV5608IYER	SPI	8	String DAC	Diesale	7 µs	Surface Mount	Voltage - Buffered	Die	10	5 V	3.3 V	2.7 V	85 °C	-40 °C	External	0.1 LSB 0.5 LSB	2.7 V	5 V	3.3 V
Texas Instruments TLV5604IDRG4	SPI	4	String DAC	16-SOIC	18 µs	Surface Mount	Voltage - Buffered	16-SOIC	10	5 V	3.3 V	2.7 V	85 °C	-40 °C	External		2.7 V	5 V	3.3 V	±0.1 ±1	0.154 in	3.9 mm
Texas Instruments TLV5604IDR	SPI	4	String DAC	16-SOIC	18 µs	Surface Mount	Voltage - Buffered	16-SOIC	10	5 V	3.3 V	2.7 V	85 °C	-40 °C	External		2.7 V	5 V	3.3 V	±0.1 ±1	0.154 in	3.9 mm
Texas Instruments TLV5604-08-31EVM	DSP MICROWIRE™ QSPI™ Serial SPI™								10														Voltage	Board(s)	4	TLV5604 TLV5608 TLV5631
Texas Instruments TLV5606IDGKRG4	SPI		String DAC		20 µs	Surface Mount	Voltage - Buffered	8-MSOP 8-TSSOP	10	5 V	3.3 V	2.7 V	85 °C	-40 °C	External	0.2 LSB 0.5 LSB	2.7 V	5 V	3.3 V								0.118 in	3 mm
