PM20205HB Series
Manufacturer: METZ CONNECT USA Inc.
Beta
⌘K
PIN HEADER, SMT, DUAL ROW, .100"
| Part | Number of Rows [custom] | Contact Type | Contact Length - Mating | Contact Length - Mating | Number of Positions | Insulation Height | Insulation Height | Contact Finish - Mating | Insulation Material | Operating Temperature [Min] | Operating Temperature [Max] | Shrouding | Pitch - Mating | Pitch - Mating | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Mounting Type | Contact Finish Thickness - Mating | Fastening Type | Contact Shape | Contact Material | Termination | Connector Type | Number of Positions Loaded | Insulation Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 METZ CONNECT USA Inc. | 2 | Male Pin | 3 mm | 0.118 in | 10 | 0.098 " | 2.5 mm | Gold | Polyethylene | -40 C | 105 ░C | Unshrouded | 0.1 " | 2.54 mm | 0.1 in | 2.54 mm | Right Angle Surface Mount | Flash | Push-Pull | Square | Copper Zinc | Solder | Header | All | Black |
