L26 Series
Manufacturer: Quectel
Beta
⌘K
EVAL BOARD FOR L26
| Part | Type | Supplied Contents | For Use With/Related Products | Utilized IC / Part | Package / Case | Frequency | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply [Max] | Voltage - Supply [Min] | Antenna Type | Data Rate | Mounting Type | RF Family/Standard | Serial Interfaces | Sensitivity | Protocol |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Quectel | GNSS | Accessories Board(s) Cable(s) | L26 | ||||||||||||||
 Quectel | AG3331 | 24-SMD Module | 1.561 GHz 1.575 GHz 1.602 GHz | 85 °C | -40 °C | 2.9 V | 2.7 V | Antenna Not Included | 921.6 kbps | Surface Mount | Navigation | I2C UART | -165 dBm | Beidou Galileo GLONASS GNSS GPS | |||
 Quectel | STA8089FG | 24-SMD Module | 1.561 GHz 1.575 GHz 1.602 GHz | 85 °C | -40 °C | 3.6 V | 3 V | Antenna Not Included | 921.6 kbps | Surface Mount | Navigation | UART | -162 dBm | Beidou Galileo GLONASS GNSS GPS | |||
 Quectel | STA8089FG | 24-SMD Module | 85 °C | -40 °C | 3.6 V | 3 V | Antenna Not Included | Surface Mount | Navigation | Beidou Galileo GLONASS GNSS GPS | |||||||
 Quectel | 24-SMD Module | Antenna Not Included | Surface Mount | Navigation | Beidou Galileo GLONASS GNSS GPS | ||||||||||||
 Quectel | MT3333 | 24-SMD Module | 1.575 GHz 1.602 GHz | 85 °C | -40 °C | 4.3 V | 2.8 V | Antenna Not Included | 115.2 kbps | Surface Mount | Navigation | UART | -167 dBm | GLONASS GNSS GPS | |||
Quectel | Transceiver | Board(s) | L26-T | ||||||||||||||
Quectel | STA8089FG | 24-SMD Module | 1.561 GHz 1.575 GHz 1.602 GHz | 85 °C | -40 °C | 3.6 V | 3 V | Antenna Not Included | 921.6 kbps | Surface Mount | Navigation | UART | -162 dBm | Beidou Galileo GLONASS GNSS GPS |
