9001 Series
Manufacturer: Oupiin
Beta
⌘K
DIN41612, FEMALE, C TYPE, 96 PIN
| Part | Operating Temperature (Max) | Operating Temperature (Min) | Material Flammability Rating | Current Rating | Material - Insulation | Contact Finish | Termination | Connector Type | Mounting Type | Pitch | Contact Finish Thickness | Contact Finish Thickness (string set options) | Contact Finish Thickness | Number of Positions Loaded | Number of Positions | Number of Rows | Style | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Press-Fit | Female Sockets Receptacle | Through Hole | 0.1 in | 0 | Flash | Flash | All | 96 | 3 | C | |
Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Solder | Female Sockets Receptacle | Through Hole | 0.1 in | 0 | Flash | Flash | All | 96 | 3 | C | |
Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Solder | Female Sockets Receptacle | Through Hole | 0.1 in | 0 | Flash | Flash | All | 96 | 3 | C | |
Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Press-Fit | Female Sockets Receptacle | Through Hole | 0.1 in | 0 | Flash | Flash | All | 64 | 2 | C | |
 Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | Glass Filled Polyester Thermoplastic | Gold | Solder | Header Male Pins | Through Hole | 0.1 in | 0 | Flash | Flash | All | 64 | 2 | R | |
 Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Solder | Header Male Pins | Through Hole | 0.1 in | 0 | Flash | Flash | All | 48 | 3 | R/2 (1/2 R) | |
 Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Solder | Female Sockets Receptacle | Right Angle Through Hole | 0.1 in | 0 | Flash | Flash | All | 96 | 3 | R | |
 Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Solder | Female Sockets Receptacle | Through Hole | 0.1 in | 0 | Flash | Flash | All | 32 | 2 | B/2 (1/2 B) | Board Lock |
Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | Glass Filled Polyester Thermoplastic | Gold | Solder | Header Male Pins | Through Hole | 0.1 in | 0 | Flash | Flash | All | 96 | 3 | R | |
Oupiin | 125 °C | -55 °C | UL94 V-0 | 2 A | PBT Polybutylene Terephthalate | Gold | Solder | Female Sockets Receptacle | Through Hole | 0.1 in | 0 | Flash | Flash | All | 64 | 2 | C |
