39112 Series

Catalog

HOOK-UP STRND 12AWG WHITE

Part	Jacket (Insulation) Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Wire Gauge	Cable Type	Ratings	Jacket Color	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Material	Length	Length	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
Belden Inc. 39112 0091000	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	White	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned	304.8 m	1000 ft	0.111 "	2.82 mm
Belden Inc. 39112 0051000	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Green	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned	304.8 m	1000 ft	0.111 "	2.82 mm
Belden Inc. 39112 0131000	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Blue	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned	304.8 m	1000 ft	0.111 "	2.82 mm
Belden Inc. 39112 0075000	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Violet	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned			0.111 "	2.82 mm
Belden Inc. 39112 189100	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Green Yellow Stripe	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned			0.111 "	2.82 mm	100 ft	30.5 m
Belden Inc. 39112 008100	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Gray	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned			0.111 "	2.82 mm	100 ft	30.5 m
Belden Inc. 39112 002100	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Red	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned			0.111 "	2.82 mm	100 ft	30.5 m
Belden Inc. 39112 009100	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	White	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned			0.111 "	2.82 mm	100 ft	30.5 m
Belden Inc. 39112 003100	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Orange	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned			0.111 "	2.82 mm	100 ft	30.5 m
Belden Inc. 39112 0135000	Polyphenylene Oxide (PPO)	0.3 mm	0.012 in	12 AWG	Hook-Up	UL Style 11028	Blue	30 AWG	65	600 V	-40 C	105 ░C	Copper Tinned			0.111 "	2.82 mm
