392-010 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 10POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Number of Positions/Bay/Row | Gender | Pitch | Pitch | Card Type | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows [custom] | Read Out | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Termination | Contact Type | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 5 | Female | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Copper Alloy | -40 C | 105 ░C | 2 | Dual | 0.25 Ám | 10 Áin | Through Hole | Wire Wrap | Cantilever | Black | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 10 | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | -40 C | 105 ░C | Single | 0.25 Ám | 10 Áin | Through Hole | Solder | Cantilever | Black | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 1 | 1 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 5 | Female | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Copper Alloy | -40 C | 105 ░C | 2 | Dual | 0.25 Ám | 10 Áin | Through Hole | Wire Wrap | Cantilever | Black | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 5 | Female | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Copper Alloy | -40 C | 105 ░C | 2 | Dual | 0.25 Ám | 10 Áin | Through Hole | Wire Wrap | Cantilever | Black | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 5 | Female | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Copper Alloy | -40 C | 105 ░C | 2 | Dual | 0.25 Ám | 10 Áin | Right Angle Through Hole | Solder Wire Wrap | Cantilever | Black | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 10 | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | -40 C | 105 ░C | Single | 0.25 Ám | 10 Áin | Through Hole | Solder | Cantilever | Black | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 5 | Female | 0.1 " | 2.54 mm | Non Specified - Dual Edge | Copper Alloy | -40 C | 105 ░C | 2 | Dual | 0.25 Ám | 10 Áin | Through Hole | Solder | Cantilever | Black | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 10 | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | -40 C | 105 ░C | Single | 0.25 Ám | 10 Áin | Through Hole | Solder | Cantilever | Black | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 10 | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | -40 C | 105 ░C | Single | 0.25 Ám | 10 Áin | Through Hole | Wire Wrap | Cantilever | Black | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 1 | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | 10 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 10 | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | Copper Alloy | -40 C | 105 ░C | Single | 0.25 Ám | 10 Áin | Through Hole | Wire Wrap | Cantilever | Black | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 1 |
