HEDS-9700 Series

Catalog

ROTARY ENCODER OPTICAL 400PPR

Part	Encoder Type	Orientation	Actuator Type	Termination Style	Output Type	Pulses per Revolution	Mounting Type	Voltage - Supply [Max]	Voltage - Supply [Min]
Broadcom Limited HEDS-9700#H51	Optical	Vertical	Codewheel Not Included	Terminal Pins	Quadrature (Incremental)	400	Chassis Mount
Broadcom Limited HEDS-9700#D55	Optical	Vertical	Codewheel Not Included	Terminal Pins	Quadrature (Incremental)	192	Chassis Mount
Broadcom Limited HEDS-9700#H54	Optical	Vertical	Codewheel Not Included	Terminal Pins	Quadrature (Incremental)	400	Chassis Mount
Broadcom Limited HEDS-9700-C54	Optical	Right Angle	Codewheel Not Included	Terminal Pins	Quadrature (Incremental)	100	Chassis Mount Motors	5.5 V	4.5 V
Broadcom Limited HEDS-9700#D50	Optical	Vertical	Codewheel Not Included	Terminal Pins	Quadrature (Incremental)	192	Chassis Mount
Broadcom Limited HEDS-9700#F52	Optical	Vertical	Codewheel Not Included	Terminal Pins	Quadrature (Incremental)	256	Chassis Mount
