Power Inductors - Leaded 22 UH 10% .65A
Power Inductors - Leaded 22 UH 10% .65A
| Part | Size / Dimension [diameter] | Size / Dimension [diameter] | Tolerance | Mounting Type | Package / Case | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Inductance Frequency - Test | Inductance | Type | DC Resistance (DCR) [Max] | DC Resistance (DCR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Murata Electronics | 0.197 in | 5 mm | 10 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 0.24 A | 1 kHz | 220 µH | Wirewound | 2.4 Ohm | |
Murata Electronics | 0.197 in | 5 mm | 10 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 350 mA | 1 kHz | 100 µH | Wirewound | 1.1 Ohm | |
 Murata Electronics | 0.197 in | 5 mm | 20 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 1.3 A | 1 kHz | 4.7 ÁH | Wirewound | 90 mOhm | |
 Murata Electronics | 0.197 in | 5 mm | 20 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 3 A | 1 kHz | 1 µH | Wirewound | 20 mOhm | |
Murata Electronics | 0.197 in | 5 mm | 10 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 950 mA | 1 kHz | 10 µH | Wirewound | 140 mOhm | |
Murata Electronics | 0.197 in | 5 mm | 10 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 140 mA | 1 kHz | 470 µH | Wirewound | 6.4 Ohm | |
Murata Electronics | 0.197 in | 5 mm | 20 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 2.4 A | 1 kHz | 1.5 µH | Wirewound | 30 mOhm | |
Murata Electronics | 0.197 in | 5 mm | 10 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 400 mA | 1 kHz | 68 µH | Wirewound | 850 mOhm | |
Murata Electronics | 0.197 in | 5 mm | 10 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 0.5 A | 1 kHz | 47 µH | Wirewound | 540 mOhm | |
 Murata Electronics | 0.197 in | 5 mm | 10 % | Through Hole | Radial Vertical Cylinder | 0.295 in | 7.5 mm | Unshielded | 85 °C | -40 C | 650 mA | 1 kHz | 22 µH | Wirewound | 270 mOhm |
