095009 Series
Manufacturer: Molex
Beta
⌘K
CONN MOD JACK 4P4C R/A UNSHLD
| Part | Number of Ports | LED Color | Ratings | Orientation | Housing Material | Number of Positions/Contacts | Connector Type | Number of Rows | Contact Finish | Termination | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Tab Direction | Features | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Shielding |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | Thermoplastic | 4p4c | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 80 C | Down | Board Lock Panel Stops | Brass | 50 µin | 1.27 µm | Unshielded |
 Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | 4p4c | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 85 °C | Down | Board Lock Panel Stops | Copper Alloy | 50 µin | 1.27 µm | Unshielded | |
 Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | 6p4c | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 85 °C | Down | Board Lock Panel Stops | Copper Alloy | 50 µin | 1.27 µm | Unshielded | |
 Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | 6p6c (RJ11 RJ12 RJ14 RJ25) | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 85 °C | Down | Copper Alloy | 50 µin | 1.27 µm | Unshielded | ||
Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | 6p4c | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 85 °C | Down | Copper Alloy | 50 µin | 1.27 µm | Unshielded | ||
Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | 6p6c (RJ11 RJ12 RJ14 RJ25) | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 85 °C | Down | Copper Alloy | 50 µin | 1.27 µm | Unshielded | ||
 Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | Thermoplastic | 8p8c (RJ45 Ethernet) | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 80 C | Down | Board Lock Panel Stops | Brass | 50 µin | 1.27 µm | Unshielded |
 Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | Thermoplastic | 6p6c (RJ11 RJ12 RJ14 RJ25) | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 80 C | Down | Board Lock Panel Stops | Brass | 50 µin | 1.27 µm | Unshielded |
 Molex | 1 | Does Not Contain LED | Cat3 | 90 ° | 8p8c (RJ45 Ethernet) | Jack | 1 | Gold | Solder | Through Hole | -40 °C | 85 °C | Down | Board Lock Panel Stops | Copper Alloy | 50 µin | 1.27 µm | Unshielded |
