333-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Read Out | Number of Positions/Bay/Row | Gender | Mounting Type | Color | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Termination | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Card Type | Features | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Dual | 24 | Female | Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Dual | 24 | Female | Board Edge Straddle Mount | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | Card Extender | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 3.96 mm | 0.156 in | Dual | 24 | Female | Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Dual | 24 | Female | Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 3.96 mm | 0.156 in | Dual | 24 | Female | Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 0.116 " | 2.95 mm | 3.96 mm | 0.156 in | Dual | 24 | Female | Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 3.96 mm | 0.156 in | Dual | 24 | Female | Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Dual | 24 | Female | Right Angle Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 0.156 " | 3.96 mm | 3.96 mm | 0.156 in | Dual | 24 | Female | Right Angle Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | -40 C | 105 ░C | Cantilever | Gold | 0.128 " | 3.25 mm | 3.96 mm | 0.156 in | Dual | 24 | Female | Through Hole | Green | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 48 | 0.25 Ám | 10 Áin | Copper Alloy | Non Specified - Dual Edge | Side Mount Opening Unthreaded |
