173-E25 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 25POS R/A SLDR
| Part | Color | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Contact Material | Number of Positions | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Mounting Type | Connector Type | Contact Finish | Backset Spacing | Backset Spacing | Flange Feature | Contact Finish Thickness | Current Rating (Amps) | Termination | Connector Style | Number of Rows [custom] | Material Flammability Rating | Contact Type | Features | Shell Material, Finish | Flange Feature | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | White | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | Brass | 25 | B DB | 3 | Steel | Yellow Chromate Plated | Panel Mount Right Angle Through Hole | Plug Male Pins | Gold | 7.2 mm | 0.283 in | 4-40 Mating Side Female Screwlock | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Mounting Brackets | |||
 NorComp Inc. | White | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | Brass | 25 | B DB | 3 | Panel Mount Right Angle Through Hole | Plug Male Pins | Gold | 7.2 mm | 0.283 in | 4-40 Mating Side Female Screwlock | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Grounding Indents Mounting Brackets | Nickel Plated Steel | ||||
 NorComp Inc. | White | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | 25 | B DB | 3 | Panel Mount Right Angle Through Hole | Plug Male Pins | Gold | 7.2 mm | 0.283 in | 4-40 Mating Side Female Screwlock | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Grounding Indents Mounting Brackets | |||||
 NorComp Inc. | White | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | Brass | 25 | B DB | 3 | Steel | Yellow Chromate Plated | Panel Mount Right Angle Through Hole | Plug Male Pins | Gold | 7.2 mm | 0.283 in | Housing/Shell (Unthreaded) | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | ||||
 NorComp Inc. | White | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | 25 | B DB | 3 | Steel | Yellow Chromate Plated | Panel Mount Right Angle Through Hole | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | 4-40 Mating Side Female Screwlock | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Mounting Brackets | ||||
 NorComp Inc. | White | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | 25 | B DB | 3 | Panel Mount Right Angle Through Hole | Plug Male Pins | Gold | 7.2 mm | 0.283 in | Housing/Shell (Unthreaded) | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Grounding Indents | |||||
 NorComp Inc. | White | 125 °C | -55 C | Polyamide (PA6T) Nylon 6T | Copper | 25 | B DB | 3 | Right Angle Through Hole | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | Housing/Shell | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Board Lock Mounting Brackets | Nickel Plated Steel | 4-40 | |||
 NorComp Inc. | White | 125 °C | -55 C | Polyamide (PA6T) Nylon 6T | Copper | 25 | B DB | 3 | Right Angle Through Hole | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | 4-40 Mating Side Female Screwlock | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Mounting Brackets | Nickel Plated Steel | ||||
 NorComp Inc. | White | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | 25 | B DB | 3 | Panel Mount Right Angle Through Hole | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | 4-40 Mating Side Female Screwlock | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Mounting Brackets | ||||||
NorComp Inc. | White | 125 °C | -55 C | Polyamide (PA6T) Nylon 6T | Copper | 25 | B DB | 3 | Right Angle Through Hole | Receptacle Female Sockets | Gold | 7.2 mm | 0.283 in | Mating Side Standard Screws (4-40) | Flash | 5 A | Solder | D-Sub | 2 | UL94 V-0 | Signal | Mounting Brackets | Nickel Plated Steel | 500 V |
