ATMEGA48 Series

Manufacturer: Atmel

Catalog

IC MCU 8BIT 4KB FLASH 32TQFP

Part	Core Size	Program Memory Type	EEPROM Size	Number of I/O	Package / Case	Oscillator Type	Speed	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Data Converters	Supplier Device Package	Core Processor	Program Memory Size	Operating Temperature [Max]	Operating Temperature [Min]	Connectivity	Mounting Type	RAM Size	Package / Case	Package / Case
Atmel ATMEGA48A-AU	8-Bit	FLASH	256 x 8	23	32-TQFP	Internal	20 MHz	1.8 V	5.5 V	A/D 8x10b	32-TQFP (7x7)	AVR	4 KB	85 C	-40 ¯C	I2C SPI UART/USART	Surface Mount	512 x 8
Atmel ATMEGA48P-20MMU	8-Bit	FLASH	256 x 8	23	28-VFQFN Exposed Pad	Internal	20 MHz	2.7 V	5.5 V	A/D 8x10b	28-VQFN (4x4)	AVR	4 KB	85 C	-40 ¯C	I2C SPI UART/USART	Surface Mount	512 x 8
Atmel ATMEGA48PA-PN	8-Bit	FLASH	256 x 8	23	28-DIP	Internal	20 MHz	1.8 V	5.5 V	A/D 6x10b	28-PDIP	AVR	4 KB	105 °C	-40 °C	I2C SPI UART/USART	Through Hole	512 x 8	7.62 mm	0.3 in
Atmel ATMEGA48PV-10PU	8-Bit	FLASH	256 x 8	23	28-DIP	Internal	10 MHz	1.8 V	5.5 V	A/D 6x10b	28-PDIP	AVR	4 KB	85 C	-40 ¯C	I2C SPI UART/USART	Through Hole	512 x 8	7.62 mm	0.3 in
Atmel ATMEGA48A-MU	8-Bit	FLASH	256 x 8	23	32-VFQFN Exposed Pad	Internal	20 MHz	1.8 V	5.5 V	A/D 8x10b	32-VQFN (5x5)	AVR	4 KB	85 C	-40 ¯C	I2C SPI UART/USART	Surface Mount	512 x 8
Atmel ATMEGA48A-CCU	8-Bit	FLASH	256 x 8	23	132-UFBGA	Internal	20 MHz	1.8 V	5.5 V	A/D 8x10b	32-UFBGA (4x4)	AVR	4 KB	85 C	-40 ¯C	I2C SPI UART/USART	Surface Mount	512 x 8
Atmel ATMEGA48V-10MMH	8-Bit	FLASH	256 x 8	23	28-VFQFN Exposed Pad	Internal	10 MHz	1.8 V	5.5 V	A/D 8x10b	28-VQFN (4x4)	AVR	4 KB	85 C	-40 ¯C	I2C SPI UART/USART	Surface Mount	512 x 8
