BD50FC0WFP Series

1A 5V, Fixed Output, High-Accuracy LDO Regulator

Catalog

1A 5V, Fixed Output, High-Accuracy LDO Regulator

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output (Min/Fixed)	Output Configuration	Protection Features	Current - Quiescent (Iq)	Current - Output	Package / Case	Supplier Device Package	Number of Regulators	Voltage - Input (Max) [Max]	Control Features	Voltage Dropout (Max) [Max]	Mounting Type
Rohm Semiconductor BD50FC0WFP-E2	85 °C	-25 °C	5 V	Positive	Over Current Over Temperature	2.5 mA	1 A	TO-252-5 DPAK (4 Leads + Tab)	TO-252-5	1	26.5 V	Enable	0.7 V	Surface Mount

Catalog

1A 5V, Fixed Output, High-Accuracy LDO Regulator

Description

BD50FC0WFP is low-saturation regulators. BD50FC0WFP output voltage is 5.0V and package is TO252-5. BD50FC0WFP has a built-in over-current protection circuit that prevents the destruction of the IC due to output short circuits and a thermal shutdown circuit that protects the IC from thermal damage due to overloading.
