87422 Series

Catalog

CONN HEADER VERT 80POS 2.54MM

Part	Contact Material	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Positions	Termination	Contact Length - Post	Contact Length - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Mounting Type	Insulation Color	Number of Rows [custom]	Contact Length - Mating	Contact Length - Mating	Connector Type	Contact Type	Pitch - Mating	Pitch - Mating	Insulation Material	Fastening Type	Shrouding	Contact Finish - Mating	Insulation Height [z]	Insulation Height [z]	Style	Overall Contact Length	Overall Contact Length	Contact Shape
TE Connectivity AMP Connectors 4-87422-0	Phosphor Bronze	0.1 in	2.54 mm	80	Solder	0.52 in	13.21 mm	0.76 Ám	30 Áin	All	Through Hole	Black	2	8.08 mm	0.318 in	Header	Male Pin	0.1 "	2.54 mm	Glass Filled Nylon Polyamide (PA)	Push-Pull	Unshrouded	Gold	0.09 in	2.29 mm	Board to Board Cable	23.55 mm	0.927 in	Square
