6609014 Series

Manufacturer: TE Connectivity Corcom Filters

Catalog

PWR ENT RCPT IEC320-C14 PNL SLDR

Part	Mounting Type	Current Rating - Appliance Inlet	Connector Style	Voltage Rating - Appliance Inlet [Min]	Voltage Rating - Appliance Inlet [Max]	Termination	Connector Type	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Filter Type	Approval Agency	Current Rating - Filter	Panel Cutout Dimensions	Features
TE Connectivity Corcom Filters 6609014-6	Panel Mount Flange Through Hole Right Angle	3 A	IEC 320-C14	120 VAC	250 VAC	Solder	Receptacle Male Blades	30.48 mm	22.86 mm	Filtered (EMI RFI) - Commercial	CSA UL VDE	3 A
TE Connectivity Corcom Filters 6609014-8	Flange Panel Mount	3 A	IEC 320-C14	120 VAC	250 VAC	Wire Leads	Receptacle Male Blades			Filtered (EMI RFI) - Commercial	CSA UL VDE	3 A	Variable Size	Front or Rear Side Mount
TE Connectivity Corcom Filters 6609014-3	Flange Panel Mount Right Angle	1 A	IEC 320-C14	120 VAC	250 VAC	Wire Leads	Receptacle Male Blades	30.48 mm	22.86 mm	Filtered (EMI RFI) - Commercial	CSA UL VDE	1 A
TE Connectivity Corcom Filters 1-6609014-2	Flange Panel Mount	6 A	IEC 320-C14	120 VAC	250 VAC	Wire Leads	Receptacle Male Blades			Filtered (EMI RFI) - Commercial	CSA UL VDE	6 A	Variable Size	Front or Rear Side Mount
TE Connectivity Corcom Filters 6609014-2	Panel Mount Flange Through Hole Right Angle	1 A	IEC 320-C14	120 VAC	250 VAC	Solder Eyelet	Receptacle Male Blades	30.48 mm	22.86 mm	Filtered (EMI RFI) - Commercial	CSA SEV UL VDE	1 A
TE Connectivity Corcom Filters 6609014-7	Flange Panel Mount Right Angle	3 A	IEC 320-C14	120 VAC	250 VAC	Wire Leads	Receptacle Male Blades	30.48 mm	22.86 mm	Filtered (EMI RFI) - Commercial	CSA UL VDE	3 A
