LCYX Series
Manufacturer: Panduit Corp
Beta
⌘K
TERMINALS COPPER COMP. LUG, 2 HOLE, #8 AWG FLEX, 1
| Part | Diameter - Ring ID [diameter] | Diameter - Ring ID [diameter] | Contact Finish | Diameter - Barrel ID [diameter] | Diameter - Barrel ID [diameter] | Contact Material | Diameter - Barrel OD [diameter] | Diameter - Barrel OD [diameter] | Mounting Type | Stud/Tab Size | Terminal Type | Length - Overall [x] | Length - Overall [x] | Color | Termination | Terminal Style | Wire Gauge [Max] | Wire Gauge [Min] | Tab Thickness | Tab Thickness | Width - Outer Edges [y] | Width - Outer Edges [y] | Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panduit Corp | 14.22 mm | 0.56 " | Electro-Tin | 0.18 in | 4.57 mm | Copper | 6.86 mm | 0.27 in | Free Hanging (In-Line) | 0.5 Stud | Rectangular Tongue | 4.08 in | 103.63 mm | Red | Barrel Crimp | Two Stud Holes | 8 AWG | 6 AWG | 0.12 in | 3.05 mm | 21.08 mm | 0.83 in | Non-Insulated |
