MP1542 Series

Catalog

MP1542 700KHZ/1.3MHZ CURRENT MODE BOOST CONVERTER EVALUATION BOARD

Part	Board Type	Supplied Contents	Outputs and Type	Outputs and Type	Contents	Voltage - Output	Main Purpose	Current - Output	Voltage - Input [Max]	Voltage - Input [Min]	Utilized IC / Part	Regulator Topology	Outputs and Type [custom]	Function	Voltage - Input (Max) [Max]	Mounting Type	Frequency - Switching	Number of Outputs	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Min) [Min]	Output Type	Output Configuration	Topology	Voltage - Output (Max) [Max]	Package / Case	Package / Case	Supplier Device Package	Voltage - Output (Min/Fixed)
Monolithic Power Systems Inc. EV1542DK-SEPIC-00A	Fully Populated	Board(s)	1	1 Non-Isolated Output Non-Isolated	Board(s)	3.3 V	DC/DC Step Up	500 mA	4.2 V	3 V	MP1542	Boost
Monolithic Power Systems Inc. EV1542DK-TFT-00A	Fully Populated	Board(s)	3	Non-Isolated Non-Isolated Outputs	Board(s)	-8 V 9 V 26 V	DC/DC Step Up	5 mA 10 mA 150 mA	3.6 V	3 V	MP1542	Boost	3
Monolithic Power Systems Inc. MP1542DK-LF-P								2 A						Step-Up	22 V	Surface Mount	1.3 MHz	1	85 C	-40 ¯C	2.5 V	Adjustable	Positive	Boost	22 V	8-MSOP 8-TSSOP	0.118 in 3 mm Width	8-MSOP	3 V
Monolithic Power Systems Inc. MP1542DK-LF-Z								2 A						Step-Up	22 V	Surface Mount	1.3 MHz	1	85 C	-40 ¯C	2.5 V	Adjustable	Positive	Boost	22 V	8-MSOP 8-TSSOP	0.118 in 3 mm Width	8-MSOP	3 V
Monolithic Power Systems Inc. EV1542DK-00A				1 Non-Isolated Output	Board(s)	8 V	DC/DC Step Up	400 mA	6 V	2.5 V	MP1542	Boost
