FN9274 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

AC POWER ENTRY MODULES 6A 3.2MH 0.22UF FAST-ON FRNT MNT MED

Part	Filter Type	Approval Agency	Mounting Type	Current Rating - Filter	Ingress Protection	Connector Type	Connector Style	Termination	Termination	Termination	Features	Number of Positions	Material Flammability Rating	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Max]	Panel Thickness [Min]	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]
TE Connectivity AMP Connectors FN9274B-6-05	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Flange Panel Mount	6 A	IP40	Receptacle Male Blades	IEC 320-C18	6.3 mm	Quick Connect	0.25 "	Front Side Mount	2	UL94 V-0
TE Connectivity AMP Connectors FN9274S1B-4-05	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Panel Mount Snap-In	4 A	IP40	Receptacle Male Blades	IEC 320-C18	6.3 mm	Quick Connect	0.25 "		2	UL94 V-0	2.5 mm	0.039 in	0.098 in	1 mm	23.2 mm	28.4 mm
TE Connectivity AMP Connectors FN9274MB-2-05	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Flange Panel Mount	2 A	IP40	Receptacle Male Blades	IEC 320-C18	6.3 mm	Quick Connect	0.25 "	Rear Side Mount	2	UL94 V-0
TE Connectivity AMP Connectors FN9274S1B-15-07	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Panel Mount Snap-In	15 A	IP40	Receptacle Male Blades	IEC 320-C18		Wire Leads			2	UL94 V-0	2.5 mm	0.039 in	0.098 in	1 mm	23.2 mm	28.4 mm
TE Connectivity AMP Connectors FN9274B-1-05	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Flange Panel Mount	1 A	IP40	Receptacle Male Blades	IEC 320-C18	6.3 mm	Quick Connect	0.25 "	Front Side Mount	2	UL94 V-0
TE Connectivity AMP Connectors FN9274MB-6-07	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Flange Panel Mount	6 A	IP40	Receptacle Male Blades	IEC 320-C18		Wire Leads		Rear Side Mount	2	UL94 V-0
TE Connectivity AMP Connectors FN9274S1B-1-05	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Panel Mount Snap-In	1 A	IP40	Receptacle Male Blades	IEC 320-C18	6.3 mm	Quick Connect	0.25 "		2	UL94 V-0	2.5 mm	0.039 in	0.098 in	1 mm	23.2 mm	28.4 mm
TE Connectivity AMP Connectors FN9274MB-6-05	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Flange Panel Mount	6 A	IP40	Receptacle Male Blades	IEC 320-C18	6.3 mm	Quick Connect	0.25 "	Rear Side Mount	2	UL94 V-0
TE Connectivity AMP Connectors FN9274B-6-07	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Flange Panel Mount	6 A	IP40	Receptacle Male Blades	IEC 320-C18		Wire Leads		Front Side Mount	2	UL94 V-0
TE Connectivity AMP Connectors FN9274MB-15-05	Filtered (EMI RFI) - Commercial Medical	CE CQC CSA ENEC UL	Flange Panel Mount	15 A	IP40	Receptacle Male Blades	IEC 320-C18	6.3 mm	Quick Connect	0.25 "	Rear Side Mount	2	UL94 V-0
