807-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 14POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Color | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Gender | Termination | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Contact Material | Number of Positions | Read Out | Card Type | Flange Feature | Contact Type | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Female | Solder | Right Angle Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Copper Alloy | 14 | Dual | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Wire Wrap | Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Copper Alloy | 7 | Single | Non Specified - Single Edge | Semi Bellows | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Wire Wrap | Through Hole | 125 °C | -40 C | Tin | Copper Alloy | 7 | Single | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | Semi Bellows | 1 | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Female | Solder | Right Angle Through Hole | 125 °C | -40 C | Tin | Copper Alloy | 14 | Dual | Non Specified - Dual Edge | Semi Bellows | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Female | Solder Eyelet(s) | Through Hole | 125 °C | -40 C | Tin | Copper Alloy | 14 | Dual | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | Semi Bellows | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Female | Solder | Right Angle Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Copper Alloy | 14 | Dual | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Wire Wrap | Through Hole | 125 °C | -40 C | Tin | Copper Alloy | 7 | Single | Non Specified - Single Edge | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | Right Angle Through Hole | 125 °C | -40 C | Tin | Copper Alloy | 7 | Single | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | Through Hole | 125 °C | -40 C | 0.25 Ám | 10 Áin | Gold | Copper Alloy | 7 | Single | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 7 | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Solder | Right Angle Through Hole | 125 °C | -40 C | Tin | Copper Alloy | 7 | Single | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | Semi Bellows | 1 | 0.156 " | 3.96 mm |
