S9B-PH-K Series
Manufacturer: JST Sales America Inc.
Catalog
CONN HEADER R/A 9POS 2MM
| Part | Number of Positions Loaded | Contact Shape | Contact Type | Shrouding | Termination | Pitch - Mating [x] | Pitch - Mating [x] | Voltage Rating | Style | Fastening Type | Insulation Material | Number of Positions | Contact Length - Mating | Contact Length - Mating | Insulation Color | Insulation Height | Insulation Height | Contact Finish - Post | Material Flammability Rating | Contact Length - Post [x] | Contact Length - Post [x] | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Connector Type | Mounting Type | Contact Material | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 JST Sales America Inc. | All | Square | Male Pin | Shrouded - 4 Wall | Press-Fit Solder | 0.079 in | 2 mm | 100 V | Board to Cable/Wire | Detent Lock | Polyamide (PA66) Nylon 6/6 | 9 | 0.13 in | 3.3 mm | Natural | 4.8 mm | 0.189 in | Tin | UL94 V-0 | 0.134 in | 3.4 mm | -25 °C | 85 °C | 2 A | Header | Through Hole Right Angle | Brass | 1 |
JST Sales America Inc. | All | Square | Male Pin | Shrouded - 4 Wall | Press-Fit Solder | 0.079 in | 2 mm | 100 V | Board to Cable/Wire | Detent Lock | Polyamide (PA66) Nylon 6/6 | 9 | Gray | 4.8 mm | 0.189 in | Tin | UL94 V-0 | 0.134 in | 3.4 mm | -25 °C | 85 °C | 2 A | Header | Through Hole Right Angle | Copper Alloy | 1 |
