EVU-E3 Series
Manufacturer: Panasonic Industrial Automation Sales
Beta
⌘K
POT 5K OHM 1/20W LOGARITHMIC
| Part | Built in Switch | Actuator Length [x] | Actuator Length [x] | Number of Gangs | Taper | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Mounting Type | Termination Style | Power (Watts) | Power (Watts) | Number of Turns | Tolerance | Actuator Type | Rotation | Adjustment Type | Resistance (Ohms) | Bushing Thread | Size - Body [x] | Size - Body [y] | Size - Body [y] | Size - Body [x] | Resistance (Ohms) | Actuator Length [z] | Actuator Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Industrial Automation Sales | Detent | 0.689 in | 17.5 mm | 1 | Logarithmic | 0.236 in | 6 mm | Snap In Through Hole | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 5 kOhms | ||||||||
 Panasonic Industrial Automation Sales | Detent | 0.689 in | 17.5 mm | 1 | Logarithmic | 0.236 in | 6 mm | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | M9 x 0.75 | 0.49 " | 9.7 mm | 0.382 " | 12.5 mm | 10k | ||||
 Panasonic Industrial Automation Sales | Detent | 1 | Logarithmic | 0.236 in | 6 mm | Snap In Through Hole | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 20 kOhms | 0.717 in | 18.2 mm | ||||||||
Panasonic Industrial Automation Sales | Detent | 1 | Linear | 0.236 in | 6 mm | Snap In Through Hole | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 50 kOhms | 0.717 in | 18.2 mm | ||||||||
Panasonic Industrial Automation Sales | Detent | 0.689 in | 17.5 mm | 1 | Linear | 0.236 in | 6 mm | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 20 kOhms | M9 x 0.75 | 0.49 " | 9.7 mm | 0.382 " | 12.5 mm | ||||
Panasonic Industrial Automation Sales | Detent | 1 | Logarithmic | 0.236 in | 6 mm | Snap In Through Hole | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 50 kOhms | 0.717 in | 18.2 mm | ||||||||
Panasonic Industrial Automation Sales | Detent | 0.689 in | 17.5 mm | 1 | Logarithmic | 0.236 in | 6 mm | Snap In Through Hole | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 20 kOhms | ||||||||
Panasonic Industrial Automation Sales | Detent | 0.689 in | 17.5 mm | 1 | Linear | 0.236 in | 6 mm | Snap In Through Hole | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 50 kOhms | ||||||||
Panasonic Industrial Automation Sales | Detent | 0.689 in | 17.5 mm | 1 | Logarithmic | 0.236 in | 6 mm | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | 50 kOhms | M9 x 0.75 | 0.49 " | 9.7 mm | 0.382 " | 12.5 mm | ||||
Panasonic Industrial Automation Sales | Detent | 0.689 in | 17.5 mm | 1 | Linear | 0.236 in | 6 mm | Board Locks PC Pins | 0.05 W | 50 mW | 1 | 20 % | Flatted | 300 ░ | Side Adjustment | M9 x 0.75 | 0.49 " | 9.7 mm | 0.382 " | 12.5 mm | 10k |
