070567 Series

Manufacturer: Molex

Catalog

CONN HEADER VERT 62POS 2.54MM

Part	Contact Finish - Post	Number of Rows	Contact Finish - Mating	Contact Length - Mating	Contact Length - Mating	Pitch - Mating	Pitch - Mating	Connector Type	Insulation Height	Insulation Height [z]	Material Flammability Rating	Contact Length - Post [x]	Contact Length - Post [x]	Shrouding	Number of Positions	Contact Type	Applications	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Termination	Overall Contact Length	Overall Contact Length	Insulation Color	Contact Shape	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Material	Fastening Type	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions Loaded	Style
Molex 0705670131	Tin	2	Gold	8 mm	0.315 in	0.1 in	2.54 mm	Header	12.07 mm	0.475 in	UL94 V-0	5.08 mm	0.2 in	Shrouded - 4 Wall	62	Male Pin	Automotive General Purpose Lighting Medical Telecommunications	74.8 Áin	1.9 Ám	Solder	0.64 in	16.26 mm	Black	Square	2.54 mm	0.1 in	Copper Alloy	Detent Lock	Through Hole	15 µin	0.38 µm	All	Board to Cable/Wire
