USB Connectors Upright-USB A Orang G-30u Plt-Cont HiRet
USB Connectors Upright-USB A Orang G-30u Plt-Cont HiRet
| Part | Material Flammability Rating | Insulation Color | Shell/Shielding Material | Contact Finish | Termination | Number of Ports | Voltage - Rated | Mating Cycles | Number of Contacts | Mounting Feature | Shielding | Gender | Current Rating (Amps) | Features | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Specifications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Kycon, Inc. | UL94 V-0 | Orange | Stainless Steel | Gold | Solder | 1 | 30 V | 1500 | 4 | Vertical | Unshielded | Receptacle | 1.5 A | Board Lock | Through Hole | -55 C | 85 °C | USB-B (USB TYPE-B) | |
 Kycon, Inc. | Solder | 1 | 30 VAC | 1500 | 4 | Horizontal | Shielded | Receptacle | 1.5 A | Board Lock | Right Angle Through Hole | -40 C | 85 °C | USB-B (USB TYPE-B) | |||||
 Kycon, Inc. | Solder | 1 | 30 VAC | 1500 | 4 | Vertical | Shielded | Receptacle | 1.5 A | Through Hole | -40 C | 105 ░C | USB-A (USB TYPE-A) | USB 2.0 |
