628-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
VERTICAL METAL BODY D-SUB CONNECTOR ROHS COMPLIANT: YES
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Shell Size, Connector Layout | Shell Size, Connector Layout | Flange Feature | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] | Termination | Connector Style | Connector Type | Shell Material, Finish | Number of Positions | Contact Finish | Current Rating (Amps) | Contact Type | Material Flammability Rating | Features | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Through Hole | 30 Áin | 0.76 Ám | 2 | Solder | D-Sub | Receptacle Female Sockets | Nickel Plated Steel | 37 | Gold | 3 A | Signal and Power | UL94 V-0 | Shielded | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Through Hole | 2 | Solder | D-Sub | Receptacle Female Sockets | 37 | Gold | 3 A | Signal | UL94 V-0 | Shielded | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Free Hanging (In-Line) | 30 Áin | 0.76 Ám | 2 | D-Sub | Receptacle Female Sockets | 37 | Gold | 3 A | Signal and Power | UL94 V-0 | Shielded | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Through Hole | 30 Áin | 0.76 Ám | 2 | Solder | D-Sub | Receptacle Female Sockets | Nickel Plated Steel | 37 | Gold | 3 A | Signal and Power | UL94 V-0 | Board Lock Shielded | |
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Through Hole | 2 | Solder | D-Sub | Receptacle Female Sockets | 37 | Gold | 3 A | Signal | UL94 V-0 | Shielded | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Through Hole | 2 | Solder | D-Sub | Receptacle Female Sockets | Nickel Plated Steel | 37 | Gold | 3 A | Signal and Power | UL94 V-0 | Shielded | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Free Hanging (In-Line) | 2 | D-Sub | Receptacle Female Sockets | Nickel Plated Steel | 37 | Gold | 3 A | Signal | UL94 V-0 | Shielded | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Through Hole | 30 Áin | 0.76 Ám | 2 | Solder | D-Sub | Receptacle Female Sockets | 37 | Gold | 3 A | Signal and Power | UL94 V-0 | Board Lock Shielded | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Through Hole | 2 | Solder | D-Sub | Receptacle Female Sockets | 37 | Gold | 3 A | Signal and Power | UL94 V-0 | Shielded | ||||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 85 °C | Black | Brass | 4 | DC C | Board Side (4-40) | Free Hanging (In-Line) | 2 | D-Sub | Receptacle Female Sockets | Nickel Plated Steel | 37 | Gold | 3 A | Signal and Power | UL94 V-0 | Shielded |
