1776315 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN TERM STRIP 5CIRC 0.571"
| Part | Terminal Screw Material | Terminal Screw Finish | Pitch [x] | Pitch [x] | Number of Wire Entries | Bottom Termination | Operating Temperature | Number of Rows | Top Termination | Wire Gauge [Min] | Wire Gauge [Max] | Number of Circuits | Material Flammability Rating | Terminal Block Type | Color | Voltage Rating | Barrier Type | Current Rating (Amps) | Mounting Type | Material - Insulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Steel | Trivalent Zinc | 14.5 mm | 0.571 in | 10 | Closed | 212 °F | 2 | Screws | 6 AWG | 14 AWG | 5 | UL94 V-2 | Eurostyle Terminal Strip | Natural | 600 V | Enclosed | 65 A | Chassis Panel | Polyamide (PA66) Nylon 6/6 |
 TE Connectivity Raychem Cable Protection | Steel | Trivalent Zinc | 14.5 mm | 0.571 in | 20 | Closed | 212 °F | 2 | Screws | 6 AWG | 14 AWG | 10 | UL94 V-2 | Eurostyle Terminal Strip | Natural | 600 V | Enclosed | 65 A | Chassis Panel | Polyamide (PA66) Nylon 6/6 |
TE Connectivity Raychem Cable Protection | Steel | Trivalent Zinc | 14.5 mm | 0.571 in | 18 | Closed | 212 °F | 2 | Screws | 6 AWG | 14 AWG | UL94 V-2 | Eurostyle Terminal Strip | Natural | 600 V | Enclosed | 65 A | Chassis Panel | Polyamide (PA66) Nylon 6/6 |
