103329 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

Catalog

CONN HEADER R/A 33POS 2.54MM

...

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions [custom]	Contact Material	Contact Length - Post	Contact Length - Post	Number of Rows	Insulation Material	Termination	Contact Type	Contact Finish - Mating	Style	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Connector Type	Contact Finish - Post	Contact Length - Mating	Contact Length - Mating	Insulation Color	Number of Positions Loaded	Mounting Type	Material Flammability Rating	Shrouding	Fastening Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height [z]	Insulation Height [z]	Pitch - Mating	Pitch - Mating	Contact Shape	Number of Positions
TE Connectivity AMP Connectors 4-103329-0-33	2.54 µm	100 µin	33	Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin	Tin-Lead	Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square
TE Connectivity AMP Connectors 4-103329-0-26	2.54 µm	100 µin		Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin	Tin-Lead	Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square	26
TE Connectivity AMP Connectors 4-103329-0-22	2.54 µm	100 µin		Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin	Tin-Lead	Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square	22
TE Connectivity AMP Connectors 4-103329-0-11	2.54 µm	100 µin		Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin	Tin-Lead	Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square	11
TE Connectivity AMP Connectors 4-103329-0-34	2.54 µm	100 µin	34	Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin	Tin-Lead	Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square
TE Connectivity AMP Connectors 9-103329-0-34	2.54 µm	100 µin	34	Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin		Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square
TE Connectivity AMP Connectors 4-103329-0-16	2.54 µm	100 µin		Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin	Tin-Lead	Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square	16
TE Connectivity AMP Connectors 9-103329-0-39	2.54 µm	100 µin		Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin		Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square	39
TE Connectivity AMP Connectors 4-103329-0-32	2.54 µm	100 µin		Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin	Tin-Lead	Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin-Lead	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square
TE Connectivity AMP Connectors 9-103329-0-11	2.54 µm	100 µin		Copper Alloy	3.05 mm	0.12 in	1	Thermoplastic	Solder	Male Pin		Board to Board Cable	105 ░C	-65 ░C	3 A	Header Breakaway	Tin	0.23 in	5.84 mm	Black	All	Right Angle Through Hole	UL94 V-0	Unshrouded	Push-Pull	100 çin	2.54 çm	3.5 mm	0.138 "	0.1 "	2.54 mm	Square	11
