V20D202 Series

Catalog

DIODE ARRAY SCHOTTKY 200V 10A

Part	Operating Temperature - Junction [Min]	Operating Temperature - Junction [Max]	Voltage - DC Reverse (Vr) (Max) [Max]	Voltage - Forward (Vf) (Max) @ If	Package / Case	Technology	Current - Reverse Leakage @ Vr	Diode Configuration	Mounting Type	Speed	Current - Average Rectified (Io) (per Diode)	Grade	Supplier Device Package	Qualification
Vishay General Semiconductor - Diodes Division V20D202C-M3/I	-40 °C	175 ░C	200 V	900 mV	D2PAK (2 Leads + Tab) TO-263-3 Variant	Schottky	150 µA	1 Pair Common Cathode	Surface Mount	200 mA 500 ns	10 A
Vishay General Semiconductor - Diodes Division V20D202CHM3_A/I	-40 °C	175 ░C	200 V	900 mV	D2PAK (2 Leads + Tab) TO-263-3 Variant	Schottky	150 µA	1 Pair Common Cathode	Surface Mount	200 mA 500 ns	10 A	Automotive	TO-263AC (SMPD)	AEC-Q101
Vishay General Semiconductor - Diodes Division V20D202CHM3/I	-40 °C	175 ░C	200 V	900 mV	D2PAK (2 Leads + Tab) TO-263-3 Variant	Schottky	150 µA	1 Pair Common Cathode	Surface Mount	200 mA 500 ns	10 A	Automotive	TO-263AC (SMPD)	AEC-Q101
