M83513/01 Series
Manufacturer: Cinch Connectivity Solutions
Beta
⌘K
D SUB CONNECTOR, MICRO D, PLUG, MIL-DTL-83513 SERIES, 51 CONTACTS, SOLDER CUP
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Material Flammability Rating | Connector Type | Connector Style | Current Rating (Amps) | Number of Rows [custom] | Number of Positions | Contact Type | Shell Material, Finish | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Flange Feature | Mounting Type | Shell Size, Connector Layout [y] | Shell Size, Connector Layout [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | UL94 V-0 | Plug Male Pins | D-Type Micro-D | 3 A | 3 | 51 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | 0.05 | 0.05 | 50 µin | 1.27 µm | Gold | Housing/Shell (Unthreaded) | Panel Mount | ||
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | UL94 V-0 | Plug Male Pins | D-Type Micro-D | 3 A | 2 | 21 | Signal | Aluminum Alloy Electroless Nickel Plated | 50 µin | 1.27 µm | Gold | Housing/Shell (Unthreaded) | Panel Mount | 0.043 in | 0.05 in | ||
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | UL94 V-0 | Plug Male Pins | D-Type Micro-D | 3 A | 100 | Signal | Aluminum Alloy Electroless Nickel Plated | 0.05 | 0.05 | 50 µin | 1.27 µm | Gold | Housing/Shell (Unthreaded) | Panel Mount | |||
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | UL94 V-0 | Plug Male Pins | D-Type Micro-D | 3 A | 2 | 21 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | 50 µin | 1.27 µm | Gold | Housing/Shell (Unthreaded) | Panel Mount | 0.043 in | 0.05 in | ||
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | UL94 V-0 | Plug Male Pins | D-Type Micro-D | 3 A | 2 | 9 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | 50 µin | 1.27 µm | Gold | Housing/Shell (Unthreaded) | Panel Mount | 0.043 in | 0.05 in | ||
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | UL94 V-0 | Plug Male Pins | D-Type Micro-D | 3 A | 2 | 15 | Signal | Aluminum Alloy Electroless Nickel Plated | 50 µin | 1.27 µm | Gold | Housing/Shell (Unthreaded) | Panel Mount | 0.043 in | 0.05 in | ||
 Cinch Connectivity Solutions | Polyester Glass Filled | -55 C | 125 °C | Copper Alloy | UL94 V-0 | Plug Male Pins | D-Type Micro-D | 3 A | 2 | 15 | Signal | Aluminum Alloy Yellow Chromate Plated Cadmium | 50 µin | 1.27 µm | Gold | Housing/Shell (Unthreaded) | Panel Mount | 0.043 in | 0.05 in |
