68405 Series

Catalog

BERGSTIK II .100CC DR ST RAIGHT

Part	Number of Rows	Contact Length - Post [x]	Contact Length - Post [x]	Fastening Type	Contact Material	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Pitch - Mating	Pitch - Mating	Voltage Rating	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Insulation Color	Connector Type	Number of Positions	Shrouding	Contact Shape	Contact Type	Contact Length - Mating [x]	Contact Length - Mating	Current Rating (Amps)	Contact Finish - Post	Number of Positions Loaded	Material Flammability Rating	Insulation Height	Insulation Height	Contact Finish - Mating
Amphenol ICC (FCI) 68405-446HLF	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm	110 VDC	Through Hole Right Angle	2.54 çm	100 çin	Solder	Black	Header	46	Unshrouded	Square	Male Pin	0.23 in	5.84 mm	5 A	Tin	All	UL94 V-0	4.83 mm	0.19 in
Amphenol ICC (FCI) 68405-158HLF	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm	110 VDC	Through Hole Right Angle	0.76 Ám	30 Áin	Solder	Black	Header	58	Unshrouded	Square	Male Pin	0.23 in	5.84 mm	5 A		All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-130HLF	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm	110 VDC	Through Hole Right Angle	0.76 Ám	30 Áin	Solder	Black	Header	30	Unshrouded	Square	Male Pin	0.23 in	5.84 mm	5 A		All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-134	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm		Through Hole Right Angle	0.76 Ám	30 Áin	Solder	Black	Header	34	Unshrouded	Square	Male Pin	0.23 in	5.84 mm			All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-152H	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm	110 VDC	Through Hole Right Angle	0.76 Ám	30 Áin	Solder	Black	Header	52	Unshrouded	Square	Male Pin	0.23 in	5.84 mm	5 A		All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-114H	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm		Through Hole Right Angle	0.76 Ám	30 Áin	Solder	Black	Header	14	Unshrouded	Square	Male Pin	0.23 in	5.84 mm			All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-220HLF	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm	110 VDC	Through Hole Right Angle	0.38 µm	15 µin	Solder	Black	Header	20	Unshrouded	Square	Male Pin	0.23 in	5.84 mm	5 A		All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-140HLF	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm	110 VDC	Through Hole Right Angle	0.76 Ám	30 Áin	Solder	Black	Header	40	Unshrouded	Square	Male Pin	0.23 in	5.84 mm	5 A		All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-524H	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm		Through Hole Right Angle	0.38 µm	15 µin	Solder	Black	Header	24	Unshrouded	Square	Male Pin	0.23 in	5.84 mm			All	UL94 V-0	4.83 mm	0.19 in	Gold or Gold GXT™
Amphenol ICC (FCI) 68405-422HLF	2	2.41 mm	0.095 in	Push-Pull	Phosphor Bronze	2.54 mm	0.1 in	0.1 in	2.54 mm	110 VDC	Through Hole Right Angle	2.54 çm	100 çin	Solder	Black	Header	22 positions	Unshrouded	Square	Male Pin	0.23 in	5.84 mm	5 A	Tin	All	UL94 V-0	4.83 mm	0.19 in
