846-082 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 82POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Pitch | Pitch | Mounting Type | Contact Type | Read Out | Gender | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Color | Card Type | Flange Feature | Number of Positions/Bay/Row | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Number of Rows [custom] | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Right Angle Through Hole | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Through Hole | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Floating Bobbin Flush Mount | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Wire Wrap | 2 | Gold | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Board Edge Straddle Mount | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Right Angle Through Hole | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Floating Bobbin Top Mount Opening | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Board Edge Straddle Mount | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold | Card Extender | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Through Hole | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Through Hole | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Through Hole | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Floating Bobbin Flush Mount | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Wire Wrap | 2 | Gold | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Board Edge Straddle Mount | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Floating Bobbin Top Mount Opening | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold | 0.116 " | 2.95 mm | Card Extender |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Right Angle Through Hole | Cantilever | Dual | Female | 82 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 41 | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 2 | Gold |
